P. 70
CALIPERS Schut for Precision
Mitutoyo calipers
Mitutoyo calipers suitable for outside, inside, height and depth measurements. Measuring jaws and
knives with beveled measuring faces for measuring small grooves and bores.
Measuring range: 0 - 300 mm. Thread table on the back side
Vernier: 0.05 mm / 1/128 inch or 0.02 mm. (only 531.122/530.316).
Flat depth rod (except 530.102: round depth
Matt chrome-plated beam and vernier.
rod ø 1.9 mm). Lapped, hardened steel measuring faces.
Raised sliders. Tungsten carbide outside measuring jaws
(only 530.320/335).
Tungsten carbide inside measuring jaws
(only 530.335).
530.104
Item No. Measuring Vernier Accuracy Jaw length Price
range/mm mm mm mm EUR
Locking screw on top: ± 0.03 40 46.00
530.122 1 0 - 150 0.02 ± 0.03 50 75.00
530.123 1 0 - 200 0.02 ± 0.04 64 229.00
530.124 1 0 - 300 0.02
Locking screw on top: ± 0.05 40 39.00
530.104 0 - 150 0.05 ± 0.05 50 94.00
530.114 0 - 200 0.05 ± 0.08 64 224.00
530.115 0 - 300 0.05
Locking screw on top: ± 0.05 40 59.00
530.102 1 0 - 150 0.05 ± 0.05 40 38.00
530.101 1 0 - 150 0.05
531.122 Locking screw on top: 40 146.00
530.320 1 0 - 150 0.05 ± 0.05
Locking screw on top: 40 230.00
530.335 1 0 - 150 0.05 ± 0.05
Locking screw on the bottom-side: 40 66.00
530.316 0 - 150 0.05 ± 0.05
Spring release: 0.05 ± 0.05 40 47.00 C02.278.EN.20250106
531.122 0 - 150 0.05 ± 0.05 50 110.00
531.108 0 - 200 0.05 ± 0.08 64 245.00
531.109 0 - 300
1 Without inch graduation.
