CALIPER ACCESSORIES Schut for Precision

Universal digital calipers IP67

Large universal digital calipers made of stainless steel for internal and external mea­sure­ments. In
combination with these universal calipers many inserts are available e.g. for measuring thread. See
accessories universal digital calipers.

 Internal measuring range: 24 - 650 mm.  Interchangeable measuring inserts.
 External measuring range: 0 - 570 mm.  Many extensions and inserts available.
 Resolution: 0.01 mm.  Protection: IP67.
 Accuracy: ± 0.02 or ± 0.03 mm.  Conforms to factory standard.
 mm/inch conversion.  Delivery in a wooden case with a
 Proximity data output.
 On/off switch. manufacturer measuring report, two inserts
 Reset/preset. and two insert holders.
 Power supply: 1 battery type CR2032.

Also models with spring
system available.

Item No. Measuring range/mm Accuracy Jaw length Price
internal external mm mm EUR

ø2.5 6.5 839.024 24 - 250 0 - 210 ± 0.02 64 905.00
ø3.5 839.025 1 42 - 350 0 - 270 ± 0.03 103 1,011.00
839.026 1 42 - 450 0 - 370 ± 0.03 103 1,271.00
839.024 839.027 1 42 - 650 0 - 570 ± 0.03 103 1,673.00
12

10 Options:
495.157 Spare battery type CR2032
ø3 12 ø3.5 840.666 Proximity USB cable (2 m) 0.50
250.00
1 Inserts 837.821 and insert holders standard included.
839.025 - 27

21

Universal digital calipers accessories

Inserts for thread measurements, per pair

Pitch Item No. Price Item No. Price 839.010 - 839.018 -
mm EUR EUR 839.017 839.023

Internal meas.: External meas.:

0.4 - 0.5 839.010 179.00 839.018 179.00 Steel inserts (M2.5), per pair
0.6 - 0.9 839.011 179.00 839.019 179.00

1 - 1.75 839.014 179.00 839.020 179.00 Item No. Diameter Length Price
EUR
2 - 3 839.015 179.00 839.021 179.00 A/mm B/mm
3.5 - 5 839.016 179.00 839.022 179.00 62.00
5.5 - 7 839.017 179.00 839.023 179.00 837.818 1.5 12 62.00
837.819 2 12 62.00
62.00
837.820 2.5 12 62.00
62.00
Insert holders (M2.5), per piece C 837.821 3 12 62.00
62.00
837.822 3.5 12 62.00
62.00
Item No. Length C/mm Price EUR 837.823 4 12 67.00
837.824 4.5 12 67.00
837.832 8 30.00 M2.5 ø3.5 837.825 5 12 67.00
837.833 10 30.00 837.826 5.5 12 67.00

839.054 12 49.00 B 837.827 6 12
839.055 20 58.00 837.828 6.5 12
839.056 50 83.00 837.829 7 18 C02.358.EN.20240625

A ø4 M2.5 837.830 8 18

837.831 10 18
