Schut Geometrical Metrology CALIPERS

Workshop calipers

Large and solid, stainless steel calipers with a matt chrome-plated beam and vernier.

 Measuring range: 0 - 2000 mm.  Monoblock.
 Vernier: 0.02 mm / 1/1000 inch or  Rounded jaw ends for internal measurements;

0.05 mm / 1/128 inch. measuring range ≤ 600 mm: K = 10 mm,
 Fine adjustment. measuring range > 600 mm: K = 20 mm.
 With or without measuring knives for internal  Locking screws.
 Delivery in a wooden case.
or external measurements.

I II

J1 J2 909.621
J2
909.633
C02.318.EN.20240625
K +0.01
0

Vernier 0.05 mm / 1/128 inch Vernier 0.02 mm / 1/1000 inch

Item No. Measuring Length Price Item No. Measuring Length Price
range mm EUR range mm EUR
mm J1 J2 K mm J1 J2 K

Without measuring knives: 97.00 Without measuring knives: 97.00
909.670 0 - 300 90 – 10 177.00 909.671 0 - 300 90 – 10 177.00
909.620 0 - 450 150 – 10 183.00 909.615 0 - 450 150 – 10 183.00
909.621 0 - 500 150 – 10 197.00 909.616 0 - 500 150 – 10 197.00
909.622 0 - 600 150 – 10 384.00 909.617 0 - 600 150 – 10 384.00
909.623 0 - 800 150 – 20 445.00 909.618 0 - 800 150 – 20 472.00
909.624 0 - 1000 150 – 20 980.00 909.619 0 - 1000 150 – 20 980.00
909.639 1 0 - 1500 200 – 20 1,335.00 909.641 1 0 - 1500 200 – 20 1,335.00
909.640 1 0 - 2000 200 – 20 909.642 1 0 - 2000 200 – 20

Meas. knives for internal measurements (I): Meas. knives for internal measurements (I):
909.672 0 - 300 90 22 10 126.00 909.673 0 - 300 90 22 10 126.00
909.632 0 - 400 100 46 10 176.00 909.625 0 - 400 100 46 10 185.00
909.633 0 - 500 150 46 10 263.00 909.626 0 - 500 150 46 10 263.00
909.634 0 - 600 150 46 10 315.00 909.627 0 - 600 150 46 10 315.00
909.635 0 - 750 150 54 20 583.00 909.628 0 - 750 150 55 20 583.00
909.636 0 - 1000 150 54 20 669.00 909.629 0 - 1000 150 55 20 669.00
909.637 1 0 - 1500 200 66 20 1,344.00 909.630 1 0 - 1500 200 66 20 1,344.00
909.638 1 0 - 2000 200 66 20 1,633.00 909.631 1 0 - 2000 200 66 20 1,633.00

Meas. knives for external measurements (II): Meas. knives for external measurements (II):
909.674 0 - 300 90 22 10 132.00 909.675 0 - 300 90 22 10 132.00
909.656 0 - 400 100 46 10 185.00 909.663 0 - 400 100 46 10 194.00
909.657 0 - 500 150 46 10 291.00 909.664 0 - 500 150 46 10 290.00
909.658 0 - 600 150 46 10 330.00 909.665 0 - 600 150 46 10 330.00
909.659 0 - 750 150 54 20 585.00 909.666 0 - 750 150 55 20 585.00
909.660 0 - 1000 150 54 20 702.00 909.667 0 - 1000 150 55 20 703.00
909.661 1 0 - 1500 200 66 20 1,411.00 909.668 1 0 - 1500 200 66 20 1,411.00
909.662 1 0 - 2000 200 66 20 1,715.00 909.669 1 0 - 2000 200 66 20 1,715.00

1 Delivery ex Groningen, Netherlands. 1 Delivery ex Groningen, Netherlands.
