ROUGHNESS SPECIMENS Schut for Precision
Roughness specimens
Series of roughness specimens, type Microsurf, covering the nine most frequently occurring
manufacturing operations; per set eight specimens will be delivered. In addition to the roughness
value Ra in µm, the roughness value CLA in µinch and the N values are specified.
Item No. Machining- Number of Roughness Roughness Roughness Price
method specimens Ra CLA class EUR
µm µin N 130.00
per set 130.00
0.025 - 3.2 130.00
850.315 Surface grinding 8 0.025 - 3.2 1 - 125 1 - 8 130.00
850.316 Cylindr. grinding 8 0.4 - 50 1 - 125 1 - 8 130.00
850.319 Face turning 8 0.4 - 50 16 - 2000 5 - 12 130.00
850.320 Turning 8 0.4 - 50 16 - 2000 5 - 12 130.00
850.321 End milling 8 0.4 - 12.5 16 - 2000 5 - 12 130.00
850.322 Reaming & drilling 8 0.4 - 50 16 - 500 5 - 10 130.00
850.323 Horizontal milling 8 0.8 - 100 16 - 2000 5 - 12
850.325 Planing 8 0.4 - 50 32 - 4000 6 - 13
850.331 Spark erosion 8 16 - 2000 5 - 12
Available with declaration of conformity on request.
Wall chart
Eight Microsurf roughness specimens, moun
ted on a general reference chart, can be obtained
for the following manufacturing operations:
Surface grinding, cylindrical grinding, face
turning, turning, end milling, reaming & drilling,
horizontal milling and planing.
Dimensions w x h: 740 x 310 mm.
Item No. Description Price EUR C10.206.EN.20240626
850.314 Microsurf 913.00
