GAUGE BLOCKS Schut for Precision

Steel gauge blocks

Steel gauge blocks with an excellent price-performance ratio.
 Hardness: 63 - 65 HRC.
 Expansion coefficient: (11.5 ± 1)·10‑6/°C.
 Cross-section: 0.5 - 10 mm: 30 x 9 mm,

> 10 mm: 35 x 9 mm.
 ISO 3650.
 Sets delivered with a manufacturer measuring

report.
 Delivery in plastic case and sets in wooden

case.
 Empty wooden cases with cutouts and size

indications for gauge block sets are optionally
available. For these cases see wooden cases
for gauge block sets elsewhere in the catalog.

Steel gauge blocks in sets

Item Class Price Size Increment Pie-
No. EUR mm mm ces

M32: 2 85.00 1.005 – 1
906.622 1 135.00 1.01 - 1.09 0.01 9
906.621 0 236.00 1.1 - 1.9 0.1 9
906.620 1 - 9 1 9
10 - 30 10 3 Steel gauge blocks, per piece
50 – 1

M47: 2 128.00 1.005 – 1 Size Increment ISO 3650/1 ISO 3650/0
906.625 1 208.00 1.01 - 1.09 0.01 9 mm mm Price EUR Price EUR
906.624 0 329.00 1.1 - 1.9 0.1 9
906.623 1 - 24 1 24 0.5 – 21.90 25.70
25 - 100 25 4 1 – 11.10 16.50
1.0005 – 15.50 23.00
1.001 - 1.009 0.001 11.10 16.50
M87: 1.001 - 1.009 0.001 9 1.01 - 1.50 0.01 11.10 15.00
906.613 1.6 - 2.0 0.1 11.10 15.00
906.612 2 208.00 1.01 - 1.49 0.01 49 2.5 - 7.5 0.5 11.10 15.00
906.611 1 365.00 8.0 - 10.0 0.5 11.10 15.00
0 553.00 0.5 - 9.5 0.5 19 10.5 - 25.0 0.5 14.10 17.70
30 – 17.90 22.80
10 - 100 10 10 40 – 17.90 22.80
50 – 20.10 22.80
M88: 1.0005 – 1 60 – 21.10 28.70
906.628 70 – 21.10 28.70
906.627 2 211.00 1.001 - 1.009 0.001 9 75 – 27.30 35.00
906.626 1 371.00 80 – 27.30 35.00
0 559.00 1.01 - 1.49 0.01 49 90 – 30.20 50.00
100 – 39.10 58.00
0.5 - 9.5 0.5 19

10 - 100 10 10

M112: 1.0005 – 1
906.631
906.630 2 317.00 1.001 - 1.009 0.001 9
906.629 1 517.00
0 806.00 1.01 - 1.49 0.01 49 C11.302.EN.20240626

0.5 - 24.5 0.5 49

25 - 100 25 4
