Schut Geometrical Metrology SURFACE ROUGHNESS TESTERS
TESA Twin-Surf surface roughness tester
The TESA Twin-Surf is a compact, portable roughness tester made to measure diverse and hard
to reach places. By means of the standard supplied 8 mm clamping shaft, it is possible to place the
TESA Twin-Surf in any compatible stand. The TESA Twin-Surf has a rechargeable battery that
enables 300 measurements without the need for mains voltage.
With the OLED display and the 3 buttons on top, the roughness tester is easy to set up and the
needed parameters are easy to read.
The roughness parameters are determined through a dragging motion of the probe, which is fitted
with a diamond stylus top with a radius of 2 μm. When the probe is rotated 90° horizontally, it is also
possible to measure in the same direction, but perpendicular to the roughness tester. Because of this, it
is possible to measure in hard to reach places like crankshafts or deeper parts of your workpiece.
The TESA Twin-Surf can be connected to a PC by means of a USB cable. The Bluetooth version
offers wireless data transfer to PC or Android smartphone/tablet. With the standard supplied TESA
Data-Studio basic software and the Android App, basic measurements and graphics can be stored. A
more detailed analysis can be acquired through the TESA Data-Studio premium software.
Parameters: According to ISO 4287: Ra, Rq, Standard accessories:
Rt, Rz, Rc, Rmax, Rsm, RPc, – Twin-Surf portable roughness tester,
According to ISO 12085: Pt, R, AR, Rx, PPc. – SB51 probe,
– roughness specimen (Ra = 2.97 µm),
Parameters with premium software according – adapter for 8 mm diameter clamping shafts,
to ISO 4287: Rp, Rv, Rsk, Rku, R∆q, R∆a, – key to remove the probe protection,
Rmr rel, Rδc, Rmr(c), Pa, Pq, Pp, Pv, Pt, Pc, – main charger with EU and US charger adaptors,
RPc, R3z, Psk, Pku, PSm, P∆q, Pmr rel, Pδc, – USB A-C cable,
Pmr(c), Rk, Rpk, Rvk, A1, A2, Mr1, Mr2, – USB key including: user manual, measuring
Parameters with premium software according
to ISO 12085: Rke, Rpke, Rvke, A1e, A2e, report, declaration of conformity, TESA Data-
Mr1e, Mr2e. Studio software basic version and Android app,
– plastic carrying case.
Measuring range: Ra 0 - 50 μm,
Rt 0.05 - 200 μm. 783.656/657
90°
Resolution: 0.001 µm / 0.01 µinch. Item No. Type Price EUR
Measuring length: 0.25 - 16.0 mm). C10.305.EN.20240626
Cut-off length: 0.25 mm, 0.8 mm, 2.5 mm. 783.656 TESA Twin-Surf
mm/inch conversion. 783.657 TESA Twin-Surf BT (Bluetooth)
USB or Bluetooth data output (BT model).
Automatic switch-off.
Internal storage for 30 measurements with
additional graphics or 18000 measurements
with roughness parameters.
Measuring force: 0.75 mN (ISO 3274).
Diamond stylus tip: radius 2 µm, 90°.
Dimensions: 160 x 34 x 34 mm.
Weight: 200 g.
Power supply: AC adapter and battery.
Detailed Options: Printer for Twin-Surf
information 783.658 TESA Data-Studio Premium software
783.659 SB21 probe (for groove depth < 5 mm)
available 783.660 SB31 probe (for small bores ø 4 mm)
783.661 SB51 probe (standard)
783.657 783.662 SB121 probe (for groove depth < 20 mm)
783.663 100 mm extension
783.664
