Schut Geometrical Metrology SURFACE ROUGHNESS TESTERS
Mitutoyo Surftest SJ‑210 surface roughness tester
The portable Mitutoyo Surftest SJ‑210 is a compact tester of surface roughness parameters, that
can also function in hard-to-reach places because of the separable drive unit and probe. The diamond
stylus has a radius of 2 µm and is retracted by the drive unit. After selection of the desired parameters,
they can be read out clearly on the display. The SJ‑210 has a USB, an RS232C and a Digimatic data
output to which the Mitutoyo u-wave system can be connected for wireless data transfer. The data can
also be stored on a MicroSD card. A large selection of probes and accessories is available.
An S‑Drive unit is available on request, with a transverse tracing drive unit, for example for
measuring in narrow spaces like crankshafts. Also available on request is the Front Lift model, where
the drive lifts the diamond stylus at the end of the measurement and is retracted without touching the
surface again.
Parameters: Ra, Rc, Ry, Rz, Rq, Rt, Rmax, Filters: 2CR75, Gaussian and PC75.
Rp, Rv, R3z, Rsk, Rku, Rc, RPc, Rsm, Dimensions: 160 x 65.8 x 52.1 mm.
Rz1max, S, HSC, RzJIS, Rppi, R∆a, R∆q, Weight: display unit: 290 g,
Rlr, Rmr, Rmr(c), Rδc, Rk, Rpk, Rvk, Mr1,
Mr2, A1, A2, Vo, Rpm, tp, Htp, R, Rx, AR. drive unit: 190 g.
ISO 4287.
Resolution: 0.02 µm, 0.006 µm or 0.002 µm. Power supply: AC adapter and battery.
Traverse length: 0.3 - 17.5 mm. After use the probe can be retracted to prevent
Primary profile, roughness (R), DF profile,
the diamond stylus tip from being damaged.
R-Motif. Memory card: micro‑SD 2 GB (optional).
Measuring accuracy according JIS, ISO,
Storage for 10 000 measured profiles.
VDA, ANSI. Also probes available for example for deep
2.4" TFT color display.
Display of: roughness profile and ADC/BAC grooves or small holes.
USB and RS232C cables available.
curves. USB data analysis software can be
User rights protection (password protection).
Easy calibration procedure. downloaded for free.
Automatic switch-off.
Memory: 10 settings and 1 profile.
Go/NoGo tolerance evaluation.
Measuring speed: 0.25, 0.5 or 0.75 mm/s.
Probe: 0.75 mN / 2 μm/60°.
Cut-off lengths: 0.08 mm, 0.25 mm, 0.8 mm
and 2.5 mm.
Probe measuring range: 360 µm.
Item No. Type/description Price EUR
178.560 Surftest SJ‑210P
Options: Standard accessories: S‑Drive unit
120.210 Extension 50 mm – standard probe,
178.029 * Stand – extension cable for the probe unit C10.304.EN.20240626
120.221 Adapter for stand (ø 8 mm)
120.222 Adapter for height gauge for measuring in small spaces,
– roughness normal,
(9 x 9 mm) – setting piece for calibration,
120.218 Nosepiece for cylindrical – AC adapter,
– handy carrying bag.
workpieces
178.296 Standard insert
* Adapter 120.221 required.
