SURFACE ROUGHNESS TESTERS Schut for Precision

Mitutoyo Surftest SJ-310 surface roughness tester

The Mitutoyo Surftest SJ‑310 is a compact, portable roughness tester with the possibility to print
on location the measuring results and roughness curves with the built-in thermo printer. Measurements
can be set using the 5.7" color touch screen and measurements can be read. Measurements can be stored
on a SD memory card. On request, as for the SJ‑210, an S‑Drive or Front Lift model is available.

 Parameters: Ra, Rc, Ry, Rz, Rt, Rp, Rq, Rv, Standard accessories: Detailed
Sm, Rmax, S, Pc, R3z, Rsk, Rku, Rz1max, – standard probe, information
Rir, Rpm, mr (c), Rpk, Rvk, δc, Rk, Mr1, – roughness normal,
Mr2, Lo, Ppi, R, AR, Rx, A1, A2, Vo, HSC, – support feet, available
Rmr, SK, Tp, Htp, ∆a, ∆q, Wte, Wx, W, AW, – nosepiece for flat surface,
λa, λq, RzJIS. – nosepiece for cylinder,
– extension cable for the
 Resolution: 0.002 µm - 0.02 µm.
 Traverse length: 16 mm. probe unit,
 Measuring accuracy according ISO, VDA, – touch pen,
– touch panel protection foil,
ANSI and JIS. – printer paper (5 rolls),
 Cut-off lengths: 0.08 mm, 0.25 mm, 0.8 mm, – setting piece for calibration,
– AC adapter and battery,
2.5 mm and 8 mm. – handy carrying bag.
 Probe measuring range: 360 µm.
 Built-in printer for statistical process control.
 ISO 4287.
 Power supply: AC adapter

and battery.

Item No. Type Price EUR
178.570 Surftest SJ‑310

Mitutoyo Surftest SJ-410 surface roughness testers

The Mitutoyo Surftest SJ‑410 is unique due to its skidless measuring. Only the stylus follows the
product and no skid is used. The probe features a measuring range of 800 µm. The built-in straight
guide enables measuring the primary profile, the roughness profile and the waves. By surface radius
compensation it is possible to measure radially on a cylinder.

 Parameters: Ra, Rc, Ry, Rz, Rt, Rp, Rq, Rv,  Straightness x-axis: SJ‑411: 0.3 μm/25 mm,
Sm, Rmax, S, Pc, R3z, Rsk, Rku, Rz1max, Rir, SJ‑412: 0.5 μm/50 mm.
Rpm, mr (c), Rpk, Rvk, δc, Rk, Mr1, Mr2, Lo,  Built-in printer for statistical
Ppi, R, AR, Rx, A1, A2, Vo, HSC, Rmr, SK, Tp, process control.
Htp, ∆a, ∆q, Wte, Wx, W, AW, λa, λq, RzJIS.  ISO 4287.
 Power supply: AC adapter Detailed
 Resolution: 0.0001 µm - 0.01 µm. information
 Measuring accuracy according ISO, VDA, and battery.
available
ANSI and JIS.
 Cut-off lengths: 0.08 mm, 0.25 mm, 0.8 mm, Item No. Type Traverse Price
length/mm EUR
2.5 mm and 8 mm.
 Probe measuring range: 800 µm.

178.580 Surftest SJ‑411 25
178.582 Surftest SJ‑412 50

Option: C10.205.EN.20250106
120.731 Standard stylus 2µm/60°
