www.promet.se ANGLE PLATES / CYLINDRICAL SQUARES
Cast iron angle plates
Ground faces.
With T-slots.
Accuracy: flatness according DIN 876,
squareness according DIN 875.
Dimensions Weight DIN 876/3 and 875/2 DIN 876/2 and 875/1 DIN 876/1 and 875/0
l x w x h/mm kg Item No. Price SEK Item No. Price SEK Item No. Price SEK
403.261 2,148.00 403.267 2,652.00
150 x 75 x 100 6 403.264 1,692.00 403.273 3,204.00 403.270 3,804.00
200 x 100 x 150 11 403.276 2,316.00 403.262 5,400.00 403.268 6,228.00
275 x 150 x 200 24 403.265 4,224.00 403.274 1 7,512.00 403.271 1 9,924.00
300 x 150 x 250 33 403.277 1 5,316.00 403.263 1 11,016.00 403.269 1 13,404.00
400 x 225 x 300 54 403.266 1 8,028.00 403.275 1 18,504.00 403.272 1 22,224.00
500 x 300 x 400 105 403.278 1 13,560.00
1 Delivery ex Groningen, Netherlands.
LMW steel cylindrical squares
Ground and lapped steel cylinder for
checking squareness e.g. during the acceptation
process of machines and instruments. Out of
roundness and straightness: ≤ 1.5 µm.
Item No. Dimensions Squareness Price
mm p-p/µm SEK
852.190 ø 90 x 200 2
852.191 ø 90 x 250 2.2
852.192 ø 90 x 300 2.5
852.193 ø 90 x 350 2.8
852.194 ø 90 x 400 3
Steel cylindrical squares
Ground and lapped steel cylinder for checking squareness.
Out of roundness and straightness: ≤ 5 µm.
Delivery in a wooden case with a
manufacturer measuring report.
Item No. Dimensions Squareness Price
mm p-p/µm SEK
906.436 ø 80 x 200 3 3,372.00 C07.208.Promet.20240517
906.437 ø 80 x 315 4 3,888.00
906.438 ø 100 x 500 5 7,608.00
906.439 ø 140 x 800 7 14,256.00
