www.promet.se SQUARES / PARALLELS
Ceramic squares
Made of alumina ceramics.
Delivery in a wooden case.
908.721 908.745
Item No. Dimensions Flatness long Flatness short Squareness Price SEK
l x w x t/mm measuring face/mm measuring face/mm mm
Triangular, class A: 0.002 0.001
0.002 0.002
908.719 160 x 100 x 20 0.0025 0.002 0.004 2,580.00
0.003 0.0025 0.005 7,368.00
908.720 250 x 160 x 25 0.007 16,584.00
0.0005 0.0005 0.009 27,600.00
908.721 400 x 250 x 40 0.0005 0.0005
0.0008 0.0005
908.722 630 x 400 x 63
Triangular, class AAA:
908.726 250 x 160 x 25 0.0025 9,312.00
0.0035 20,568.00
908.727 400 x 250 x 40 0.0045 34,920.00
908.728 630 x 400 x 63
Item No. Dimensions Flatness Squareness Parallelism Price SEK
l x w x t
mm measuring measuring side measuring side
faces/mm faces/mm faces/mm faces/mm faces/mm
Rectangular, class A:
908.742 200 x 200 x 25 0.0018 0.004 0.04 0.004 0.096 7,368.00
0.0026 0.006 0.06 0.006 0.144 18,060.00
908.745 400 x 400 x 40
Rectangular, class AAA:
908.782 300 x 300 x 30 0.0006 0.0013 0.013 0.0013 0.031 15,912.00
Ceramic parallels in pairs
Parallels to position and layout workpieces in for example clamping jaws for drilling, grinding,
milling and measuring.
Made of alumina ceramics.
Delivery in a wooden case.
Item No. Dimensions Flatness measuring Parallelism measur- Squareness Height Price SEK
difference/mm
Class A: l x w x h/mm faces/mm ing faces/mm mm
908.733
400 x 63 x 40 0.008 0.008 0.030 0.008 17,460.00
Ceramic straight edge
Made of alumina ceramics.
Delivery in a wooden case.
Item No. Dimensions Flatness measuring Parallelism mea- Squareness Price
l x w x h/mm faces/mm suring faces/mm mm SEK
C07.315.Promet.20240517
Class AAA: 400 x 60 x 25 0.008 8,148.00
908.789 0.0016 0.0024
© 2024, Schut Geometrische Meettechniek bv 193 Promet Precision 2023/2024-D
