SQUARES www.promet.se

Granite squares  Delivery in an aluminum carrying case (only
height ≤ 400 mm) with a declaration of
 Triangular model. conformity.
 Material: granite.
 Straight beveled edges.
 With weight-saving holes (except 402.120

and 910.437).

Item No. Dimensions Squareness 1 Flatness 2 Weight Price
h x w x t/mm µm µm kg SEK

DIN 875/0: ± 4 2 0.31,020.00
402.120 100 x 63 x 16 ± 4 2 0.81,488.00
402.121 160 x 100 x 20 ± 9 3 25.54,740.00
402.1243 630 x 400 x 63

DIN 875/00: 0.31,404.00
910.437 100 x 63 x 16 ± 2 1 0.82,028.00
910.438 160 x 100 x 20 ± 2 1 2.42,280.00
910.439 250 x 160 x 25 ± 2.5 1 7.54,188.00
910.440 400 x 250 x 40 ± 3.5 1.2 25.56,744.00
910.4413 630 x 400 x 63 ± 4.5 1.5 102 11,988.00
910.4423,4 1000 x 630 x 80 ± 6 2.5

1 Squareness between measuring face and base.
2 Flatness of measuring face and base.
3 Delivery ex Groningen, Netherlands.
4 Weight included package.

Granite squares  Delivery in an aluminum carrying case (only
height ≤ 400 mm) with a declaration of
 Square model. conformity.
 Material: granite.
 Straight beveled edges.
 With weight-saving holes.

Item No. Dimensions Squareness Weight Price
h x w x t/mm µm 1 kg SEK

Class 0: ± 4 2.6 3,048.00
402.145 200 x 200 x 25 ± 4.5 4.9 3,612.00
402.146 250 x 250 x 30 ± 6 14.5 6,768.00
402.148 400 x 400 x 40 ± 7 33 9,372.00
402.149 2 500 x 500 x 50

Class 00: ± 2 2.6 3,336.00 402.148 C07.321.Promet.20240517
910.443 200 x 200 x 25 ± 2.2 4.9 3,912.00
910.444 250 x 250 x 30 ± 2.6 7.7 4,956.00
910.445 315 x 315 x 30 ± 3 14.5 7,788.00
910.446 400 x 400 x 40 ± 3.5 33 11,052.00
910.447 2 500 x 500 x 50

1 Squareness between adjacent measuring faces.
2 Delivery ex Groningen, Netherlands.
