P. 186
VISES www.promet.se
Precision vises
Hardened precision vises for accurate measurements and machine operations.
Accuracy (parallelism, flatness and Precision and universal sine vises
squareness): Stable and accurate to fix in each angle
≤ 100 mm jaw opening = 0.005 mm,
> 100 mm jaw opening = 0.005 mm per 100 mm. position (0 to 45°).
Universal precision vise
With horizontally and vertically ground prism With 360° rotatable base.
in the moveable jaw. Accurate degree scale.
Stable and accurate to fix in each angle
position (0 to 45°).
909.734
909.739 909.746
909.749
Item No. Jaw opening Jaw width Jaw depth Length Price 909.752
mm mm mm mm SEK
Promet Precision 2023/2024-D
Precision vises: 50 25 150 996.00
909.733 60 75 35 200 1,404.00
909.734 80 100 45 250 2,688.00
909.735 120 125 50 300 4,488.00
909.736 155
909.737 25 25 10 65 552.00
909.738 65 50 25 140 792.00
909.739 100 75 35 190 996.00
909.740 120 100 45 240 2,112.00
909.741 155 125 50 280 3,072.00
Precision sine vises with swivelling front axis:
909.742 60 50 25 140 1,452.00
909.743 100 75 35 190 1,860.00
909.744 120 100 45 250 4,140.00
Precision sine vises with swivelling rear axis:
909.745 60 50 25 140 1,572.00
909.746 100 75 35 190 1,968.00
909.747 120 100 45 250 3,336.00
Universal sine vises: 140 2,676.00 C07.309.Promet.20240517
909.748 60 50 25 200 3,840.00
909.749 90 75 35 250 6,384.00
909.750 120 100 45 300 8,400.00
909.751 155 125 50
Universal precision vise: – 11,796.00
909.752 80 70 30
© 2024, Schut Geometrische Meettechniek bv 186
