Mini indexable collets Mounting by means of two M6 threaded
bores on the bottom-side.
Clamping range: 0.4 - 6 mm.
Per approx. 45 degrees indexable. Item No. Clamping range Dimensions Price
Aluminum, blasted. mm l x w x h/mm SEK
856.091 856.090 856.090 0.4 - 3.5 26 x 21 x 34 1,596.00
856.091 1.2 - 6 26 x 26 x 39 1,596.00
Stand for mini precision vises
Stand for use with mini precision vices in combination with base plates. The base plates can also be
used with other stands. For these stands see dial indicator stands elsewhere in the catalog.
Item No. Description Price SEK 856.087 670.057 +
856.087
670.057 Stand for 856.081 and 856.082 312.00
332.40
Base plates: 374.40
856.087 For 856.081
856.088 For 856.082
856.089 For 856.083
XY table for mini precision vises
XY table for accurate positioning underneath a microscope, for example.
Dimensions: 50 x 50 x 27 mm.
Range: 10 x 10 mm.
Graduation micrometers: 0.01 mm.
Item No. Description Price SEK 856.176 +
856.177 +
856.176 XY table 11,424.00 856.081
856.177 Adapter for mini precision vise 856.081 948.00
856.178 Adapter for mini precision vise 856.082 856.177
1,200.00
Mini V-block Mini magnetic V-blocks
Dimensions: 25 x 20 x 20 mm. V‑groove: 120°.
Hardened stainless steel construction. Hardened and ground steel.
Delivery incl. aluminum clamp.
Item No. Description Price SEK Item No. 856.173 Price SEK C07.319.Promet.20240517
856.179 1,524.00 856.173 1,944.00
Mini V-block 856.174
for shafts ø 2.5 - 18 mm 856.174 2,184.00
Description
Mini V-block 20 x 20 x 17.5 mm
for shafts ø 2.0 - 25 mm
Mini V-block 30 x 30 x 25 mm
for shafts ø 4.0 - 35 mm
