Cast iron surface plates

Extra heavy, cast iron surface plates. 403.212
 Three models:
Delivery ex Groningen, Netherlands
– milled (smoothened), accuracy according
DIN 876/3,
– hand scraped, accuracy according
DIN 876/1,
– fine scraped, accuracy according
DIN 876/0.
 The side faces of all plates are milled and
varnished.
 Surface plate stand optionally available
(see “surface plate accessories” elsewhere in
this catalog).

Dimensions Weight Accuracy according Accuracy according Accuracy according
l x w kg DIN 876/3 DIN 876/1 DIN 876/0
mm (approx.)
Item No. Price SEK Item No. Price SEK Item No. Price SEK

200 x 200 7 403.236 1,272.00 403.208 1,752.00 403.185 2,100.00
250 x 250 12 403.237 1,596.00 403.209 2,280.00 403.186 2,784.00
300 x 300 15 403.238 2,208.00 403.210 3,180.00 403.187 3,792.00
400 x 250 25 403.239 2,652.00 403.211 3,660.00 403.188 4,692.00
400 x 400 35 403.240 3,432.00 403.212 5,340.00 403.189 6,504.00
500 x 500 50 403.241 5,304.00 403.213 7,896.00 403.190 9,492.00
600 x 400 45 403.242 5,028.00 403.214 7,344.00 403.191 9,132.00
630 x 630 90 403.243 9,084.00 403.215 13,008.00 403.192 15,156.00
800 x 500 95 403.249 10,272.00 403.221 14,724.00 403.193 17,388.00
1000 x 600 140 403.245 15,696.00 403.217 21,516.00 403.194 26,880.00
1000 x 1000 270 403.246 24,120.00 403.218 32,880.00 403.195 40,080.00
1200 x 800 300 403.250 25,560.00 403.222 33,120.00 403.196 40,200.00
2000 x 1000 1000 403.248 67,320.00 403.220 85,680.00

Fine scraped plate (DIN 876/1) with lapp and inspection surface

Cast iron duplex plate with one flat inspection surface
and one squared lapp surface, both finely scraped
according to DIN 876/1. With the optional wooden box the
surface plate can be used on both sides, because the top
and bottom side of the case can be separated.
 Flatness: 14 µm.
 Dimensions l x w x h:

360 x 260 x 65 mm.
 Weight: approx. 24 kg.

Item No. Description Price SEK C06.218.Promet.20240517
403.150 Duplex plate 4,716.00
403.151 Wooden case (double sided use) 900.00
