CALIPERS Schut for Precision
Mitutoyo Absolute Digimatic workshop calipers
Series of large digital calipers with the unique Absolute measuring system to prevent inaccuracy
due to an incorrect zero position. The one-time setting of origin remains as the absolute zero position
until the battery has to be changed.
Measuring range: 0 - 1000 mm. Types I and II with rounded jaw ends for
Resolution: 0.01 mm. internal measurements:
ABS/INC switchable. measuring range ≤ 300 mm: from 10 mm,
Digimatic data output. measuring range ≥ 450 mm: from 20 mm.
On/off switch.
Reset. Protection: IP40 or IP67.
Max. measuring speed: Conforms to factory standard.
Delivery in a plastic case.
unlimited. Power supply: 1 battery type V357.
With or without measuring
knives.
Locking screw.
551.301
500.500 Data cables Digimatic, USB Input Tool Direct,
U-WAVE available on request.
Item No. Measuring Accuracy Length/mm IP67 Price
range/mm mm A B EUR
ABA Type I Without measuring knives (I): 60 – IP67 413.00
B Type II 550.301 1 0 - 200 ± 0.03 75 – IP67 550.00
550.331 2 0 - 300 ± 0.04 100 –
Type III 550.203 0 - 450 ± 0.05 100 – – 758.00
550.205 0 - 600 ± 0.05 140 – – 864.00
550.207 0 - 1000 ± 0.07 – 1,462.00
With measuring knives for external measurements (II):
551.301 1 0 - 200 ± 0.03 60 30 IP67 451.00
551.331 2 0 - 300 ± 0.04 90 40 IP67 596.00
551.204 0 - 500 ± 0.06 150 56 – 960.00
551.206 0 - 750 ± 0.06 150 56 – 1,314.00
551.207 0 - 1000 ± 0.07 150 56 – 1,594.00
With measuring knives for internal measurements (III):
500.500 0 - 450 ± 0.05 90 38 – 1,015.00
500.501 0 - 600 ± 0.05 90 38 – 1,106.00
500.502 0 - 1000 ± 0.07 130 50 – 1,913.00
Option: 0.90 C02.313.EN.20240625
836.535 Spare battery type V357
A 1 Offset function.
2 Offset and preset function.
