CALIPERS Schut for Precision
Mitutoyo Digimatic carbon workshop calipers
Workshop calipers, with a data output and an ultra lightweight carbon fiber construction that saves
up to 50% of the total weight compared to a steel workshop caliper. Interchangeable measuring jaws
for special purposes (and the necessary holders) are optionally available.
Measuring range: 0 - 2000 mm, Offset function for direct read-out of internal
internal measurements from 20 mm. measurements.
Resolution: 0.01 mm. Max. measuring speed: unlimited.
ABS/INC switchable. Protection: IP66.
Digimatic data output. Conforms to factory standard.
On/off switch. Delivery in a plastic case.
Reset/preset. Power supply: 1 battery type V357.
Hold function.
552.304
914.055
552.151
914.057 Data cables Digimatic, USB Input Tool Direct,
U-WAVE available on request.
Item No. Measuring range/mm Accuracy/mm Jaw length/mm Weight/kg Price EUR
With steel measuring faces:
552.302 0 - 450 ± 0.04 100 0.7 1,152.00
552.303 0 - 600 ± 0.04 100 0.8 1,302.00
552.304 0 - 1000 ± 0.05 150 1.8 1,901.00
552.305 1 0 - 1500 ± 0.09 150 2.2 2,418.00
552.306 1 0 - 2000 ± 0.12 150 2.6 3,090.00
With ceramic measuring faces:
552.155 0 - 450 ± 0.04 100 0.7 1,695.00
552.156 0 - 600 ± 0.04 100 0.8 1,838.00
Long measuring jaws with steel measuring faces: 200
552.150 0 - 450 ± 0.06 200 1.2 1,695.00
552.151 0 - 600 ± 0.06 200 1.3 1,838.00
552.152 0 - 1000 ± 0.07 200 2.1 2,386.00
552.153 1 0 - 1500 ± 0.11 200 2.5 3,118.00
552.154 1 0 - 2000 ± 0.14 2.9 3,922.00
Options: 0.90 C02.277.EN.20240625
836.535 Spare battery type V357 272.00
914.055 2 Measuring jaws (pair) for center distances from 10 mm 312.00
914.057 2 Measuring jaws (pair) for internal groove diameters from 50 mm 209.00
914.053 2 Holders (pair) for separate measuring jaws, up to measuring range 0 - 600 mm 214.00
914.054 2 Holders (pair) for separate measuring jaws, from measuring range 0 - 1000 mm
1 Delivery ex Groningen, Netherlands.
2 Not suited for use with the workshop calipers with long measuring jaws (552.150 - 154).
