Page 59 - Schut Catalog
P. 59
Schut Geometrical Metrology CALIPERS
Digital carbon workshop calipers IP65
Workshop calipers with large measuring jaws, Bluetooth, and an ultra lightweight carbon fiber
construction that saves up to 65% of the total weight compared to a steel workshop caliper.
Measuring range: 0 - 2000 mm. Fine adjustment by means of carriage for
Resolution: 0.01 mm. constant measuring force between 5 - 10 N.
mm/inch conversion.
ABS/INC switchable. Carbon jaws with steel measuring faces.
Digimatic data output. Rounded jaw ends for internal measurements.
Bluetooth data output. Locking screw.
On/off switch. Protection: IP65.
Reset/preset. Delivery in a wooden case with a
Hold function.
manufacturer measuring report.
Power supply: 1 battery type CR2032.
910.342
L
163
A
30
USB interface:
– For data transfer to PC
(e.g. Excel, Word).
– Operating system:
Windows and other.
– PC connection: USB.
20 – No software or driver to install.
70.5 – Foot switch (optional).
Item No. Measuring Accuracy Jaw length Weight Length Price
range/mm mm A/mm kg L/mm EUR
910.342 0 - 600 ± 0.06 130 1.3 826 403.00
910.343 0 - 600 ± 0.08 200 1.4 826 468.00
910.344 0 - 600 ± 0.12 2 300 1.5 826 536.00
910.345 0 - 1000 ± 0.08 130 1.5 1226 562.00
910.346 0 - 1000 ± 0.12 200 1.6 1226 647.00
910.347 0 - 1000 ± 0.16 2 300 1.7 1226 724.00
910.349 1 0 - 1500 ± 0.16 150 2.0 1736 872.00
910.350 1 0 - 1500 ± 0.21 2 300 2.1 1736 982.00
910.352 1 0 - 2000 ± 0.21 200 2.6 2246 1,726.00
910.353 1 0 - 2000 ± 0.25 2 300 2.7 2246 1,898.00
Options: 0.50
495.157 Spare battery type CR2032 109.00
909.686 3 USB interface 18.50
909.687 Footswitch for USB interface 50.00
910.038 Wireless USB receiver 50.00
910.039 3 Wireless transmitter
1 Delivery ex Groningen, Netherlands. C02.371.EN.20240625
2 Depending on the measuring force, only valid in the upper part of the measuring jaws.
3 For instruments with a Digimatic data output.
© 2024, Schut Geometrische Meettechniek bv 59 Measuring instruments and systems 2023/2024
