Schut Geometrical Metrology DEMEET 3D CNC MEASURING MACHINES
DeMeet video and multi-sensor measuring machines
DeMeet coordinate measuring machines The accuracy of the DeMeet measuring
The DeMeet 3D CNC coordinate measuring machines is guaranteed by a CAA 3D correction
model (Computer-Aided Accuracy, error
machines provide automatic, user-independent compensation).
quality control with measuring results traceable Machine construction
to the international length standard. The
DeMeet measuring machines are available The construction is a granite base plate with
in Video (optical) and Combo model (multi- accuracy grade according to DIN 876/00, placed
sensor for combined video and touch probe on well positioned shock absorbing points
measurements). The DeMeet multi-sensor and resting on a welded base frame (for the
measuring machines are an excellent all-in- DeMeet‑220 the base plate is flat grinded cast
one alternative to other measuring devices iron).
for example a measuring microscope, profile
projector and height gauge. The XYZ base structure for the THK
precision preloaded caged ball linear guides
With an excellent price-performance ratio is made from extremely tension relieved, flat
the DeMeet measuring machines enable grinded cast iron, as the basis for a mechanical
high precision quality control in measuring accurate construction. The axis drive system
laboratories as well as on the production consists of Faulhaber high torque DC servo
floor. Applications of optical and multi-sensor motors, TFE coated Kerk lead screws and
measuring are among others in the precision Renishaw TONIC optical linear encoders with
engineering, medical, plastics and electronics low sub-divisional error.
industry.
Design and quality The measuring table is made of tension
relieved, wear-resistant, nickel-plated steel, with
The application of quality components made a mounting hole pattern for product fixtures
by Schut and by well-known, specialized and a flat aligned glass plate. The video model
manufacturers ensures excellent performance consists of a DeMeet camera with a Sony sensor
and high accurate measurements. and a telecentric optical system. In addition to
the optical system the Combo model is equipped
With the new design of the DeMeet with a Renishaw touch probe system.
measuring machine series no concessions have
been made to accuracy and reliability. The new Download the
visually screwless cover design provides a better brochure from
protection in the production environment and is
highlighted with nickel-plated aluminum details Schut.com
which can be personalized. The open design
of the DeMeet allows for easy operation and C23.301.EN.20250106
loading of the machine from all sides.
