GAUGES Schut for Precision
Plug gauges H7
Manufactured according DIN EN ISO 1938. Available from 1 - 100 mm with Go and NoGo on one
handle.
DIN 7162 and 7164.
H7 fit size in hardened steel.
With serial number.
Delivery with a manufacturer measuring report.
Individual plug gauges delivered in a plastic
tube. Set delivered in a plastic case.
Including wear allowance at the Go end.
Wear allowance
New gauges are supplemented with a wear
allowance on the Go end: z (plus) for plug gauges.
Accordingly, the size indicated on the handle is not
similar to the measured value of the new Go end.
Item No. Size H7 Price Item No. Size H7 Price Item No. Size H7 Price
mm EUR mm EUR mm EUR
911.000 1 31.60 911.023 19 18.40 911.047 47 46.00
911.001 1.5 28.40 911.024 20 20.30 911.048 48 46.00
911.002 2 16.30 911.025 21 20.30 911.049 50 46.00
911.003 2.5 15.10 911.026 22 20.30 911.050 52 54.00
911.004 3 15.10 911.027 23 20.40 911.051 55 54.00
911.005 3.5 15.10 911.028 24 20.40 911.052 58 58.00
911.006 4 15.10 911.029 25 20.40 911.053 60 58.00
911.007 4.5 15.10 911.030 26 23.10 911.054 62 58.00
911.008 5 15.10 911.031 27 23.10 911.055 65 72.00
911.009 5.5 15.10 911.032 28 23.10 911.056 68 73.00
911.010 6 12.20 911.033 30 25.80 911.057 70 76.00
911.011 7 13.60 911.034 32 25.80 911.058 72 76.00
911.012 8 13.60 911.035 33 27.60 911.059 75 84.00
911.013 9 13.60 911.036 34 28.40 911.060 78 84.00
911.014 10 13.60 911.037 35 30.00 911.061 80 88.00
911.015 11 14.60 911.038 36 30.00 911.062 82 105.00
911.016 12 14.60 911.039 37 30.00 911.063 85 105.00
911.017 13 14.60 911.040 38 30.00 911.064 88 105.00
911.018 14 14.60 911.041 40 30.00 911.065 90 112.00
911.019 15 16.00 911.042 42 36.50 911.066 92 115.00
911.020 16 16.80 911.043 44 41.00 911.067 95 118.00
911.021 17 16.80 911.044 45 46.00 911.068 98 127.00
911.022 18 16.80 911.045 46 46.00 911.069 100 131.00
Set plug gauges
Item No. Description Price EUR C12.307.EN.20240626
103.00
911.157 Plug gauges (Go + NoGo) H7: 3, 4, 5, 6, 8, 10, 12 mm
