Schut Geometrical Metrology GAUGES

LMW plug gauges

Manufactured according DIN 2245, 2246 and 2247. Available from 0.5 - 160 mm; up to 70 mm
with Go and NoGo on one handle, over 70 mm in two parts. Prices are for H7 plug gauges with Go
and NoGo ends in hardened steel.

 H7 fit size in hardened steel.
 Available from 0.5 - 160 mm; up to 70 mm

with Go and NoGo on one handle, over
70 mm in two parts.
 Including wear allowance at the Go end.

Wear allowance
New gauges are supplemented with a wear al­

lowance on the Go end: z (plus) for plug gauges.
Accordingly, the size indicated on the handle is
not similar to the measured value of the new Go
end.

Example: plug gauge 20 H7
New Go end:
size 20.000 mm
wear allowance (+ z) 0.003 mm
20.003 mm
manufacturing tolerance ± 0.002 mm Measuring reports
largest value measured 20.005 mm
smallest value measured 20.001 mm For all gauges also measuring reports can be
ordered.
Also available:  Manufacturer measuring report (German)
– larger sizes,
– without wear allowance, per gauge. Stating of product specifications,
– many other fit sizes, like H6, H8, P7, G7 etc., measured values after production, used
– hard-chrome plated plug gauges, traceable measuring devices, measuring
– tungsten carbide plug gauges, inaccuracy and measuring date. A favourable
– extended plug gauges, choice when your quality system does not
– plug gauges with vent hole, require traceable certificates.
– plug gauges with easy-entry pilot.  Traceable certificate (Dutch) with mea­suring
reports of the ordered gauges. Besides stating
of the measured values the extra assurance of
an external inspection.

Size H7 Price Size H7 Price Size H7 Price Size H7 Price Size H7 Price
mm EUR mm EUR mm EUR mm EUR mm EUR

1 73.00 10 49.00 24 71.00 42 105.00 70 180.00 C12.202.EN.20250106
1.5 67.00 11 51.00 25 73.00 44 111.00 72 188.00
2 59.00 12 50.00 26 74.00 45 114.00 75 187.00
2.5 56.00 13 54.00 27 76.00 46 117.00 78 206.00
3 48.00 14 55.00 28 78.00 47 120.00 80 209.00
3.5 46.00 15 57.00 30 79.00 48 123.00 82 224.00
4 44.00 16 59.00 32 85.00 50 127.00 85 231.00
4.5 46.00 17 57.00 33 88.00 52 133.00 88 241.00
5 41.00 18 62.00 34 90.00 55 133.00 90 236.00
5.5 43.00 19 63.00 35 92.00 58 149.00 92 254.00
6 43.00 20 63.00 36 93.00 60 155.00 95 261.00
7 42.00 21 67.00 37 91.00 62 161.00 98 271.00
8 44.00 22 68.00 38 98.00 65 158.00 100 277.00
9 45.00 23 70.00 40 96.00 68 177.00

Larger sizes available on request.
