Page 380 - Schut Catalog
P. 380
FEELER GAUGES Schut for Precision
Feeler gauges
Feeler gauge sets in a holder, for individual use or in combination to measure slits and gaps as well
as checking the amount of clearance in sliding guides, bearings, pistons etc.
Measuring range: 0.03 - 2.00 mm. Accuracy according DIN 2275 T2.
Blade length: 100 mm. Also available in brass model (anti-magnetic).
Nickel plated handle with locking screw.
Blade width: 10 mm (except stainless steel 910.021
models: 12 mm), tapered.
910.024
910.020
Item No. Number Increment(s) Material Price
of blades 0.01 mm 0.02 mm 0.05 mm 0.10 mm EUR
1.70
909.904 8 0.05 → 0.30 0.40 → 0.50 hardened steel 4.50
909.905 8 0.05 → 0.30 0.40 → 0.50 stainless steel 5.80
909.906 8 0.05 → 0.30 0.40 → 0.50 brass 2.00
5.00
909.907 13 0.05 → 0.30 0.40 → 1.00 hardened steel 9.00
909.908 13 0.05 → 0.30 0.40 → 1.00 stainless steel 3.10
909.909 13 0.05 → 0.30 0.40 → 1.00 brass 7.40
13.90
910.019 20 0.05 → 1.00 hardened steel 1.70
910.020 20 0.05 → 1.00 stainless steel 2.00
910.021 20 0.05 → 1.00 brass 2.00
2.00
910.022 8 0.03 → 0.10 hardened steel 2.80
910.023 10 0 .03 → 0.05 0.10 → 0.30 0.40 → 0.50 hardened steel 3.10
910.024 10 0.10 → 1.00 hardened steel 3.10
910.026 14 0 .03 → 0.10 0.15 → 0.30 0.40 → 0.50 hardened steel 3.40
910.027 18 0 .05 → 0.10 0.15 → 0.40 0.50 → 1.00 hardened steel 5.10
910.028 19 0.03 → 0.10 0.15 → 0.30 0.40 → 1.00 hardened steel 5.60
910.029 20 0 .04 → 0.10 0.15 → 0.50 0.60 → 1.00 hardened steel
908.978 22 0.03 → 0.05 0.10 → 1.00 hardened steel
908.979 28 0 .03 → 0.10 0.12 → 0.50 hardened steel
C11.214.EN.20240626
910.034 21 0.05 → 0.10 0.20 → 2.00 hardened steel
© 2024, Schut Geometrische Meettechniek bv 380 Measuring instruments and systems 2023/2024
