Schut Geometrical Metrology GAUGE BLOCK ACCESSORIES
Mitutoyo maintenance kit for steel gauge blocks
Contains all neccesary requirements for the
use, and maintenance, of steel gauge block.
The maintenance kit consists of:
– whetstone “Cerastone”, 100 x 25 x 12 mm,
– pair of tweezers,
– dust remover,
– cleaning cloths,
– washleather,
– pipette bottle for solvent, 100 ml,
– pair of gloves,
– wooden case.
Item No. Description Price EUR
516.650 Maintenance kit for steel gauge blocks 619.00
Mitutoyo micrometer inspection sets
These sets are composed for the inspection of micrometers according DIN 863. Micrometers with
a measuring range over 25 mm can be inspected if an extra gauge block of 25, 50 or 75 mm is used
in addition to the gauge blocks in these sets. Each set consists of ten special gauge blocks and a plan
parallel optical flat.
Nominal sizes (mm): 2.5 - 5.1 - 7.7 - 10.3 - Delivery in a wooden case with a 516.156
12.9 - 15.0 - 17.6 - 20.2 - 22.8 - 25.0. manufacturer measuring report.
Including plan parallel optical flat ø 30 x 12 mm.
Item No. Material Grade Price EUR
516.107 steel 1 449.00
516.106 steel 0 585.00
516.157 1 796.00
516.156 ceramic 0 918.00
ceramic
Mitutoyo caliper inspection set
For checking the accuracy of DIN 862 or
ISO 13385-1: 2011.
516.124: gauge blocks 30, 41.3 and 131.4 mm,
setting rings ø 4 and ø 25 mm.
516.526: gauge blocks 10, 30, 50 and 125 mm,
setting rings ø 4 and ø 25 mm,
measuring pin ø 10 mm.
Delivery in a wooden case with a manufacturer
measuring report for the gauge blocks.
Item No. Description Price EUR
516.124 Inspection set DIN 862 895.00 C11.305.EN.20240626
516.526 Inspection set ISO 13385-1: 2011 1,192.00
© 2024, Schut Geometrische Meettechniek bv 377 Measuring instruments and systems 2023/2024
