GAUGE BLOCKS Schut for Precision

Select long gauge blocks from 125 mm

High quality long steel gauge blocks. These steel gauge blocks are available in the accuracy classes
0, 1 and 2 of ISO 3650. All gauge blocks have two coupling holes on both ends so that they can be
coupled by means of a toggle clamp.

 Hardness: approx. 800 HV.  Delivery on request with a DAkkS certificate,
 Expansion coefficient: α = 11.5 · 10‑6 K‑1. UKAS acknowledged.
 Cross-section: 35 x 9 mm.
 ISO 3650.  Gauge blocks of 1000 - 1500 mm incl. a
 Delivery in a luxurious wooden case with a DAkkS certificate, UKAS acknowledged
available on request.
traceable manufacturer measuring report.

831.937

Size/mm Item No. Price EUR Item No. Price EUR Item No. Price EUR

125 ISO 3650/2: 313.00 ISO 3650/1: 398.00 ISO 3650/0: 456.00
150 831.019 335.00 831.008 426.00 831.000 489.00
175 831.020 402.00 831.009 497.00 831.001 580.00
200 831.021 431.00 831.010 517.00 831.002 620.00
250 831.022 486.00 831.011 610.00 831.003 679.00
300 831.023 542.00 831.012 653.00 831.936 772.00
400 831.024 640.00 831.013 808.00 831.937 926.00
500 831.025 701.00 831.981 931.00 831.946 1,115.00
600 831.026 1,085.00 831.738 1,256.00 831.004 1,504.00
700 831.027 1,286.00 831.014 1,519.00 831.947 1,816.00
800 831.028 1,631.00 831.015 1,944.00 831.005 2,410.00
900 831.029 2,010.00 831.016 2,490.00 831.948 3,150.00
1000 831.030 2,530.00 831.017 3,070.00 831.006 4,020.00
831.031 831.018 831.007
4,430.00
Gauge block set consisting of 125, 150, 175, 200, 250, 300, 400 and 500 mm: 831.086
10,800.00
831.088 2,880.00 831.087 3,730.00 831.089

Gauge block set consisting of 600, 700, 800, 900 and 1000 mm:

831.091 7,010.00 831.090 8,520.00

Mitutoyo toggle clamp for long series gauge blocks

Toggle clamp for the coupling of gauge blocks over 100 mm which have coupling holes on
both ends. Very quick assembly by means of spring clamping device (with locking screw).

Item No. Description Price EUR

619.031 Toggle clamp for long 159.00 C11.315.EN.20240626
series gauge blocks
