Schut Geometrical Metrology GAUGE BLOCKS

Long gauge blocks from 125 mm

Long steel gauge blocks with an excellent price-performance ratio. These steel gauge blocks are
available in the accuracy classes 0, 1 and 2 of ISO 3650. All gauge blocks have two coupling holes on
both ends so that they can be coupled by means of a toggle clamp.

 Hardness: 63 - 65 HRC.  ISO 3650.
 Expansion coefficient: (11.5 ± 1)·10‑6/°C.  Delivery in wooden case with a manufacturer
 Cross-section: 35 x 9 mm.
measuring report.

907.707

907.741

Size/mm Item No. Price EUR Item No. Price EUR Item No. Price EUR

125 ISO 3650/2: 56.00 ISO 3650/1: 66.00 ISO 3650/0: 112.00
150 907.728 91.00 907.715 92.00 907.702 169.00
175 907.729 92.00 907.716 109.00 907.703 181.00
200 907.730 99.00 907.717 124.00 907.704 185.00
250 907.731 112.00 907.718 148.00 907.705 231.00
300 907.732 159.00 907.719 159.00 907.706 356.00
400 907.733 180.00 907.720 278.00 907.707 371.00
500 907.734 200.00 907.721 417.00 907.708 478.00
600 907.735 514.00 907.722 764.00 907.709 1,041.00
700 907.736 571.00 907.723 813.00 907.710 1,333.00
800 907.737 684.00 907.724 938.00 907.711 1,631.00
900 907.738 843.00 907.725 1,154.00 907.712 1,815.00
1000 907.739 938.00 907.726 1,316.00 907.713 2,030.00
907.740 907.727 907.714

Gauge block set consisting of 125, 150, 175, 200, 250, 300, 400 and 500 mm:
907.743 586.00 907.742 733.00 907.741 1,403.00

Gauge block set consisting of 600, 700, 800, 900 and 1000 mm: 907.744 C11.301.EN.20240626
907.746 2,640.00 907.745 4,000.00 6,500.00
