GAUGE BLOCK ACCESSORIES Schut for Precision
Gauge block accessories
Various accessories to extract the resulting size of one or more gauge blocks outside or to convert
it into an inside gauge. This also enables the creation of setting gauges and marking tools. These
accessories considerably increase the applicability of standard gauge blocks.
907.204
907.210
907.209
907.202
Item No. Description Price Set
EUR M8 M10 M12
Holder for gauge blocks: 907.207
907.203 Up to 50 mm 27.00 • • • 907.213
907.204 Up to 100 mm 37.30 • • • 907.211 907.212
907.205 Up to 200 mm 56.00 • • •
Pair of measuring jaws, with measuring faces:
907.206 Cylindrical ø 2 mm and flat (l = 40 mm) 76.00 • • •
907.207 Cylindrical ø 5 mm and flat (l = 45 mm) 72.00 • • •
907.208 Cylindrical ø 10 mm and flat (l = 70 mm) 63.00 • •
907.209 Flat (l = 100 mm, h = 19 mm) 69.00 • •
907.213 V‑shaped (l = 60 mm, max. ø 60 mm) 46.00 • •
907.210 Straight edge (l = 100 mm) 12.20 •
907.211 Scriber (l = 45 mm) 46.00 • • •
907.212 Center point (l = 45 mm) 75.00 • • •
907.214 Base for holder (h = 25 mm) 168.00 • •
Accessory sets, delivered in a case:
907.200 M8 598.00 C11.275.EN.20240626
907.201 M10 804.00
907.202 M12 762.00
