Schut Geometrical Metrology STICK MICROMETERS
Inside micrometers with interchangeable anvils
Screw thread micrometers for internal measurements of pitch diameters. The interchangeable anvils
allow measurements of several kinds of screw thread.
Measuring range: 75 - 300 mm. Insert shaft: ø 5 mm.
Graduation: 0.01 mm. Delivery incl. setting gauge for metric thread,
Locking screw (125 - 300 mm).
60° flank angle.
Item No. Measuring Accuracy Price Item No. Threads per inch Price EUR
range/mm mm EUR
Inserts for Whitworth threads,
Inside micrometers without inserts: 55° flank angle, per pair:
906.924 75 - 100 ± 0.035 87.00 906.940 60 - 48 22.30
906.925 100 - 125 ± 0.035 98.00 906.941 48 - 40 22.30
906.926 125 - 150 ± 0.035 108.00 906.942 40 - 32 22.30
906.927 150 - 175 ± 0.035 118.00 906.944 32 - 24 22.30
906.928 175 - 200 ± 0.045 129.00 906.945 24 - 18 22.30
906.929 200 - 225 ± 0.045 139.00 906.946 18 - 14 22.30
906.930 225 - 250 ± 0.045 149.00 906.947 14 - 10 22.30
906.931 250 - 275 ± 0.045 160.00 906.948 10 - 7 22.30
906.932 275 - 300 ± 0.055 170.00 906.949 7 - 4.5 22.30
906.950 4.5 - 3.5 22.30
906.951 Set 60 - 3.5 186.00
Item No. Pitch/mm Price EUR Item No. Threads per inch Price EUR
Inserts for metric threads, 22.30 Inserts for UN, UNC and UNF threads,
60° flank angle, per pair: 22.30 60° flank angle, per pair:
906.933 0.4 - 0.5 22.30 906.952 64 - 48 22.30
906.934 0.6 - 0.9 22.30 906.953 44 - 28 22.30
906.935 1 - 1.75 22.30 906.954 24 - 14 22.30
906.936 2 - 3 22.30 906.955 13 - 9 22.30
906.937 3.5 - 5 111.00 906.956 8 - 5 22.30
906.938 5.5 - 7 906.957 4.5 - 3.5 22.30
C04.282.EN.20240625
906.939 Set 0.4 - 7 906.958 Set 64 - 3.5 111.00
