INTERNAL MICROMETERS Schut for Precision
Three-point internal micrometers
Three-point internal micrometers for accurately measuring (blind) bores.
Measuring range: ø 6 - 300 mm. Measuring heads > ø 150 mm:
Graduation: 0.001 mm (ø 6 - 12 mm), – with interchangeable
measuring bolts,
0.005 mm (ø 12 - 300 mm). – star-shaped.
Self-centering.
Tungsten carbide measuring faces.
Interchangeable measuring bolts from
measuring range ø 150 - 175 mm.
Delivery in an aluminum case (ø 6 - 40 mm)
or an aluminum carrying case (ø 40 - 300 mm
and sets) with extension 150 mm
(ø 6 - 12 mm: 100 mm).
Separate instruments within measuring range
ø 6 - 100 mm and the sets are delivered incl.
setting ring(s).
Setting rings are conform to factory standard.
908.654
908.662
Measuring head ø 50 - 100 mm ø 100 - 300 mm For blind bores C04.203.EN.20250106
(measuring range)
ø 6 - 50 mm
