MICROMETERS Schut for Precision

Dial snap gauges

Snap gauges with adjustable anvil and clamping shaft for a dial indicator. Especially suitable for
Go/NoGo determination and batch measurements.

 Measuring range: 0 - 300 mm.  For suitable dial indicators refer to the dial
 Measuring force: 6 - 9 N. indicators elsewhere in this catalog.
 Clamping shaft: ø 8 mm (dial gauge not

included).
 Travel of moving anvil: 3 mm.
 Anvil size: 14 x 11 mm.
 Chamfered anvils for easy insertion.
 Delivery in a wooden case.

Item No. Measuring Length/mm Price
range/mm A B EUR
906.237
906.237 0 - 25 42 20 203.00 + 907.879
906.238 25 - 50 69 32.5 227.00
906.239 50 - 75 94 45 255.00 0K in mm 36 A 28
906.240 75 - 100 119 57.5 287.00 Set ABS INC B
906.241 100 - 125 144 70 311.00
906.242 125 - 150 169 82.5 335.00 14 x 11 mm ø15
906.243 150 - 175 194 95 359.00
906.244 175 - 200 219 107.5 383.00
906.245 200 - 225 244 120 407.00
906.246 225 - 250 269 132.5 431.00
906.247 250 - 275 294 145 455.00
906.248 275 - 300 319 157.5 479.00

Digital vertical micrometers

Digital vertical micrometers for easy reading, for example, when measuring the thickness of metal
or plastic sheet. These micrometers have an IP65 classification and are therefore not only resistant to
dust but can also withstand water jets.

 Measuring range: 0 - 50 mm.  On/off switch.
 Resolution: 0.001 mm.  Automatic switch-off.
 Accuracy: ± 0.002 mm.  Tungsten carbide measuring faces: ø 6.5 mm.
 mm/inch conversion.  Protection: IP65.
 ABS/INC switchable.  Delivery in a wooden case.
 Power supply: 1 battery type V357.

Item No. Measuring range/mm Price EUR

909.458 0 - 25 175.00
909.459 25 - 50 205.00

909.458 Option: C03.320.EN.20240625
836.535 Spare battery type V357
0.90
