www.promet.se MICROMETER ACCESSORIES
Setting gauges Setting standards
Cylindrical gauges for micrometers with flat Cylindrical setting standards for micrometers
parallel measuring faces. with prism-shaped anvil.
Measuring faces L < 100 mm: ø 7 mm, flat,
L < 300 mm: ø 8 mm, flat,
L ≥ 300 mm: ø 8 mm, spherical.
With plastic insulating grip.
Larger sizes available on request.
907.464 909.326
Item No. Length Accuracy Price Item No. Diameter/mm Price SEK
mm µm SEK 909.323 5 153.60
909.324 453.60
907.464 25 ± 2 57.60 909.325 20 504.00
907.465 50 ± 2 66.00 909.326 25 528.00
907.466 75 ± 2.5 82.80 909.327 35 552.00
907.467 100 ± 2.5 106.80 909.328 45 648.00
907.468 125 ± 3 133.20 909.329 50 912.00
907.469 150 ± 3 150.00 909.330 65
907.470 175 ± 3.5 174.00 909.331 80 1,224.00
907.471 200 ± 4 199.20 85 1,320.00
907.472 225 ± 4 222.00
907.473 250 ± 4 254.40 Setting standards
907.474 275 ± 4.5 277.20
907.475 300 ± 4.5 540.00 Hardened steel setting standards for threads
907.476 325 ± 5 540.00 with 55° or 60° flank angle.
907.477 350 ± 5 648.00
907.478 375 ± 5.5 540.00 909.305
907.479 400 ± 5.5 648.00
907.480 425 ± 6 576.00 Item No. Length/mm Price SEK
907.481 450 ± 6 696.00
907.482 475 ± 6.5 576.00 For threads with 60° flank angle: 516.00
907.483 500 ± 6.5 696.00 909.304 25
907.484 525 ± 7 708.00 909.305 50 600.00
907.485 575 ± 7.5 708.00 909.306 75 684.00
907.486 625 ± 7.5 840.00 909.307 100 792.00
907.487 675 ± 8 840.00 909.308 125 912.00
907.488 725 ± 8.5 948.00 909.309 150 1,044.00
907.489 775 ± 9.5 948.00 909.310 175 1,200.00
907.490 825 ± 10 1,092.00 909.311 200 1,380.00
907.491 875 ± 10.5 1,092.00
907.492 925 ± 11 1,332.00 For threads with 55° flank angle: 516.00
907.493 975 ± 11.5 1,332.00 909.312 25
907.494 1050 ± 12 1,860.00 909.313 50 600.00
907.495 1150 ± 13 1,860.00 909.314 75 684.00
907.496 1250 ± 14 2,244.00 909.315 100 792.00
907.497 1350 ± 15 2,244.00 909.316 125 912.00
907.498 1450 ± 16 2,676.00 909.317 150 1,044.00 C03.219.Promet.20240517
909.529 1 1550 ± 17 2,676.00 909.318 175 1,200.00
909.530 1 1650 ± 18 3,216.00 909.319 200 1,380.00
909.531 1 1750 ± 19 3,216.00
909.532 1 1850 ± 20 3,852.00
909.533 1 1950 ± 21 3,852.00
1 Delivery ex Groningen, Netherlands.
