www.promet.se MICROMETERS

Thread measuring wires

For measuring external threads using the three-wire method. The flank diameter can be determined
according to the measured diameter, using tables.
 For micrometers with measuring faces ø 6.35,

ø 6.5 or ø 8 mm. (Also available for measuring
faces ø 6.8 and ø 7.5 mm.)
 Very high measuring accuracy: ± 0.001 mm.
 In pairs or in a set.
 The wire holders are held in position on the
anvil and spindle by a spring clamp.
 The wires are mounted on the holder in
such a way that they position themselves
on the thread.

d2 dD
M
C03.244.Promet.20240517
Thread measuring wires for micrometers with measuring faces ø 6.35, ø 6.5 or ø 8 mm

ø 6.35 mm ø 6.5 mm ø 8 mm Wire Metric, W hitworth, UN/UNC/UNF,
Item No. Price Item No. Price Item No. Price diameter
SEK SEK SEK dD/mm pitch threads threads

833.442 1,968.00 779.161 1,968.00 836.689 1,968.00 in mm per inch per inch
833.443 1,968.00 781.651 1,968.00 836.690 1,968.00
833.444 1,968.00 779.162 1,968.00 836.691 1,968.00 0.17 0.25; 0.3 – –
833.445 1,968.00 779.163 1,968.00 835.844 1,968.00 0.195 80
833.446 1,968.00 779.164 1,968.00 834.499 1,968.00 0.22 – – 72
833.447 1,968.00 779.165 1,968.00 834.498 1,968.00 0.25 64
833.448 1,968.00 781.652 1,968.00 837.848 1,968.00 0.29 0.35 – 56
833.449 1,968.00 779.166 1,968.00 833.872 1,968.00 0.335 48; 44
833.450 1,968.00 779.167 1,968.00 834.585 1,968.00 0.390 0.4 – 40
833.451 1,968.00 779.168 1,968.00 834.480 1,968.00 0.455 36
833.452 1,968.00 779.169 1,968.00 834.586 1,968.00 0.53 0.45; 0.5 – 32; 28
833.453 1,968.00 779.170 1,968.00 834.290 1,968.00 0.62 24
833.454 1,968.00 779.171 1,968.00 834.502 1,968.00 0.725 0.6 40 20
833.455 1,968.00 779.172 1,968.00 834.291 1,968.00 0.895 18; 16
833.456 1,968.00 779.173 1,968.00 833.871 1,968.00 1.10 – – 14; 13
833.457 1,968.00 779.174 1,968.00 834.292 1,968.00 1.35 12; 11
833.458 1,968.00 779.175 1,968.00 834.416 1,968.00 1.65 0.7 - 0.8 – 10; 9
833.459 1,968.00 779.176 1,968.00 834.483 1,968.00 2.05 8; 7
837.501 6,144.00 837.642 6,144.00 834.509 6,144.00 2.55 – 32; 28 6
3.20 5; 4.5
834.580 36,480.00 779.160 36,480.00 834.581 36,480.00 4.00 1 26; 24 4

1.25 22; 20; 19

1.5 18; 16

1.75 14

2 12; 11

2.5 10; 9

3.0; 3.5 8; 7

4.0; 4.5 6

5.0; 5.5 5; 4.5

6.0 4; 3.5

Set with wire diameters 0.17 to 3.20 mm
