Screw thread micrometers (continued)

Measuring inserts for screw thread micrometers with clamping shaft ø 5 mm.

Item No. Threads per inch Price SEK

Measuring inserts for Whitworth threads,
55° flank angle, per pair:
906.730 60 - 48 285.60
906.731 48 - 40 285.60
906.725 906.732 40 - 32 285.60

906.733 32 - 24 285.60
906.734 24 - 18 285.60
906.735 18 - 14 285.60
906.736 14 - 10 285.60
906.737 10 - 7.0 285.60
906.738 7.0 - 4.5 285.60
906.739 4.5 - 3.5 285.60

906.740 Set 60 - 3.5 2,232.00

Item No. Pitch/mm Price SEK Item No. Threads per inch Price SEK

Measuring inserts for metric threads, Measuring inserts for UN, UNC and UNF
60° flank angle, per pair: threads, 60° flank angle, per pair:
906.720 0.4 - 0.5 285.60 906.741 64 - 48 285.60
906.721 0.6 - 0.9 285.60 906.742 44 - 28 285.60
906.722 1.0 - 1.75 285.60 906.743 24 - 14 285.60
906.723 2.0 - 3.0 285.60 906.744 13 - 9 285.60
906.724 3.5 - 5.0 285.60 906.745 8 - 5 285.60
906.725 5.5 - 7.0 285.60 906.746 4.5 - 3.5 285.60

906.726 Set 0.4 - 7.0 1,332.00 906.747 Set 64 - 3.5 1,332.00

909.305

Item No. Length/mm Price SEK Item No. Length/mm Price SEK

Hardened steel setting standards for threads Hardened steel setting standards for threads
with 60° flank angle: with 55° flank angle:
909.304 25 516.00 909.312 25 516.00
909.305 50 600.00 909.313 50 600.00
909.306 75 684.00 909.314 75 684.00
909.307 100 792.00 909.315 100 792.00
909.308 125 912.00 909.316 125 912.00
909.309 150 1,044.00 909.317 150 1,044.00
909.310 175 1,200.00 909.318 175 1,200.00 C03.241.Promet.20240517
909.311 200 1,380.00 909.319 200 1,380.00
