MICROMETERS www.promet.se

Micrometers with prism-shaped anvil

Analog and digital micrometers with prism-shaped anvil for measuring the diameters of objects with
an odd number of flutes such as taps, reamers and mills. The angle of the prism aperture is designed
for 3‑, 5‑ or 7‑fluted workpieces.

 Measuring range: 1 - 105 mm. Digital
 Analog: graduation 0.01 mm,  mm/inch conversion.
 ABS/INC switchable.
digital: resolution 0.001 mm.  Automatic switch-off.
 Spindle: ø 6.5 mm.  Reset/preset.
 Tungsten carbide measuring faces. The  Protection: IP65.
 Power supply: 1 battery type V357.
906.160 and 909.866 have a pointed spindle
for the smallest objects.
 V‑groove for:
3‑fluted objects: 60°,
5‑fluted objects: 108°,
7‑fluted objects: 128° 34' 17".
 Delivery in a plastic case, with a setting
standard.

909.866

906.161

Item No. Measuring Accuracy Price Item No. Price
range/mm mm SEK SEK

For 3‑fluted objects (60°), analog: Digital: Setting standards
906.160 1 - 15 ± 0.004 1,704.00 909.866 2,652.00
906.161 5 - 20 ± 0.004 1,776.00 909.867 2,712.00 Item No. ø Price
906.162 20 - 35 ± 0.005 2,124.00 909.868 2,964.00 mm SEK
906.163 35 - 50 ± 0.005 2,616.00 909.869 3,336.00
906.164 50 - 65 ± 0.006 2,808.00 909.870 3,384.00
906.165 65 - 80 ± 0.006 3,036.00 909.871 3,552.00
907.060 80 - 95 ± 0.007 3,276.00 909.872 3,732.00
Digital:
For 5‑fluted objects (108°), analog: 909.873 2,700.00 909.323 5 153.60
906.166 5 - 25 ± 0.004 1,764.00 909.874 3,072.00 909.324 20 453.60
906.167 25 - 45 ± 0.005 2,268.00 909.875 3,324.00 909.325 25 504.00
906.168 45 - 65 ± 0.006 2,616.00 909.876 3,636.00 909.326 35 528.00
906.169 65 - 85 ± 0.007 3,036.00 909.877 3,948.00 909.327 45 552.00
907.061 85 - 105 ± 0.008 3,456.00 Digital: 909.328 50 648.00
909.878 2,700.00 909.329 65 912.00
For 7‑fluted objects (128° 34' 17"), analog: 909.879 3,072.00 909.330 80 1,224.00
906.170 5 - 25 ± 0.004 1,764.00 909.880 3,324.00 909.331 85 1,320.00
906.171 25 - 45 ± 0.005 2,268.00 909.881 3,636.00
906.172 45 - 65 ± 0.006 2,616.00
906.173 65 - 85 ± 0.007 3,036.00 10.80
Option: C03.233.Promet.20240517

836.535 Spare battery type V357 909.326
