www.promet.se DEPTH MICROMETERS
Depth micrometers
Depth micrometers with interchangeable, spherical or flat rods. With the flat rods mainly flat and
spherical surfaces can be measured very accurately. The spherical rods are especially suitable for
beveled and hollow surfaces. The high accuracy of the rods makes recalibration after exchanging the
rods unnecessary. Two models with different base lengths available.
Measuring range: 0 - 300 mm. Measuring rods: ø 4.5 mm.
Graduation: 0.01 mm. Locking screw.
906.970
906.040
Model with spherical rods especially for hollow and beveled surfaces
Item No. Price Item No. Price Measuring Accuracy Number
SEK SEK range/mm mm of rods
1
Base 63 mm: Base 101.5 mm: 0 - 25 ± 0.005 2
906.964 540.00 906.040 540.00 0 - 50 ± 0.005 4
906.965 648.00 906.039 648.00 0 - 100 ± 0.006 6
906.966 816.00 906.041 816.00 0 - 150 ± 0.007 8
906.967 1,056.00 906.042 1,056.00 0 - 200 ± 0.008 12
906.968 1,524.00 906.043 1,524.00 0 - 300 ± 0.009
906.969 2,112.00 906.044 2,112.00 Number
of rods
Model with flat rods especially for flat and spherical surfaces 1
2
Item No. Price Item No. Price Measuring Accuracy 4
SEK SEK range/mm mm 6
8
Base 63 mm: Base 101.5 mm: 0 - 25 ± 0.005 12 C02.275.Promet.20240517
906.970 768.00 906.976 768.00 0 - 50 ± 0.005
906.971 912.00 906.977 912.00 0 - 100 ± 0.006
906.972 1,272.00 906.978 1,272.00 0 - 150 ± 0.007
906.973 1,524.00 906.979 1,524.00 0 - 200 ± 0.008
906.974 1,884.00 906.980 1,884.00 0 - 300 ± 0.009
906.975 2,472.00 906.981 2,472.00
