Page 89 - Schut Catalog
P. 89
www.promet.se MICROMETER HEADS
Digital micrometer heads
Several digital micrometer heads with different possibilities.
Measuring range: 0 - 50 mm. Memory absolute measuring value.
Resolution: 0.001 mm. Preset for ABS measurement.
Accuracy: ± 0.003 mm Friction thimble.
Power supply: 1 battery type V357.
(909.900/901: ± 0.005 mm).
mm/inch conversion.
ABS/INC switchable.
On/off switch.
Automatic switch-off.
L2 (max) L1 909.897
Item No. Measuring Dimensions/mm Description Price
range/mm spindle clamping L1 L2 measuring faces SEK
With IP65 protection: ø 6.5 ø 12 x 17.5 115 46 flat, tungsten carbide measuring face1,308.00
909.897 0 - 25 ø 6.5 ø 12 x 17.5 115 46 spherical 1,308.00
909.898 0 - 25 ø 6.5 ø 12 x 17.5 116 56 flat, non-rotating tip 1,332.00
909.899 0 - 25 ø 7.5 ø 12 x 35.5 140 89 flat, tungsten carbide measuring face2,088.00
909.900 0 - 50 ø 7.5 ø 12 x 35.5 140 89 spherical 2,088.00
909.901 0 - 50
With non-rotating spindle: flat, tungsten carbide measuring face1,704.00
909.902 0 - 25 ø 7.5 ø 12 x 10 124 39 interchangeable measuring inserts 1,740.00
909.903 0 - 25 ø 7.5 ø 12 x 10 123 39
Option: 10.80
836.535 Spare battery type V357
Interchangeable measuring inserts for 909.903 No. Item No. Description Price
measuring faces SEK
1 ø6.5 15 ø5 0.7 5
2 ø6.5 4.5 ø0.3 60° 6 Measuring inserts, per pair: 190.80
3 ø2 0.35 60° 7 906.788 flat 228.00
SR 5 906.789 spherical 343.20
4 906.790 small 343.20 C03.317.Promet.20240517
906.791 disc 456.00
4 ø12 906.792 knife/flat 343.20
906.793 point 576.00
906.794 knife 1,932.00
906.795 Set of 7 pairs
© 2024, Schut Geometrische Meettechniek bv 89 Promet Precision 2023/2024-D
