www.promet.se GAUGE BLOCKS
Long gauge blocks from 125 mm
Long steel gauge blocks with an excellent price-performance ratio. These steel gauge blocks are
available in the accuracy classes 0, 1 and 2 of ISO 3650. All gauge blocks have two coupling holes on
both ends so that they can be coupled by means of a toggle clamp.
Hardness: 63 - 65 HRC. ISO 3650.
Expansion coefficient: (11.5 ± 1)·10‑6/°C. Delivery in wooden case with a manufacturer
Cross-section: 35 x 9 mm.
measuring report.
907.707
907.741
Size/mm Item No. Price SEK Item No. Price SEK Item No. Price SEK
ISO 3650/2: 672.00 ISO 3650/1: 792.00 ISO 3650/0: 1,344.00
125 907.728 907.715 907.702
150 907.729 1,092.00 907.716 1,104.00 907.703 2,028.00
175 907.730 1,104.00 907.717 1,308.00 907.704 2,172.00
200 907.731 1,188.00 907.718 1,488.00 907.705 2,220.00
250 907.732 1,344.00 907.719 1,776.00 907.706 2,772.00
300 907.733 1,908.00 907.720 1,908.00 907.707 4,272.00
400 907.734 2,160.00 907.721 3,336.00 907.708 4,452.00
500 907.735 2,400.00 907.722 5,004.00 907.709 5,736.00
600 907.736 6,168.00 907.723 9,168.00 907.710 12,492.00
700 907.737 6,852.00 907.724 9,756.00 907.711 15,996.00
800 907.738 8,208.00 907.725 11,256.00 907.712 19,572.00
900 907.739 10,116.00 907.726 13,848.00 907.713 21,780.00
1000 907.740 11,256.00 907.727 15,792.00 907.714 24,360.00
Gauge block set consisting of 125, 150, 175, 200, 250, 300, 400 and 500 mm: 16,836.00
907.743 7,032.00 907.742 8,796.00 907.741
C11.301.Promet.20240517
Gauge block set consisting of 600, 700, 800, 900 and 1000 mm: 907.744 78,000.00
907.746 31,680.00 907.745 48,000.00
