www.promet.se GAUGE BLOCKS

Ceramic gauge blocks

Ceramic gauge blocks with an excellent price-performance ratio, made of Zirconia ceramics.
Because of this, these gauge blocks are highly durable, corrosion proof and completely stable for
long-term use.

 Highly wear-resistant. Can be used 5 to 10  Hardness: 88 - 90 HRC.
times longer than steel gauge blocks.  Expansion coefficient: (9.2 ± 1)·10‑6/°C.
 Cross-section: 0.5 - 10 mm: 30 x 9 mm,
 Rustproof.
> 10 mm: 35 x 9 mm.
 ISO 3650.
 Sets delivered with a manufacturer measuring

report.
 Delivery in plastic case and sets in wooden

case.
 Empty wooden cases with cutouts and size

indications for gauge block sets are optionally
available. For these cases see wooden cases
for gauge block sets elsewhere in the catalog.

Ceramic gauge blocks in sets

Item Class Price Size Increment Pie-
No. SEK mm mm ces

Ceramic gauge blocks, per piece M32: 1 12,420.00 1.005 – 1
906.646 0 15,528.00 1.01 - 1.09 0.01 9
906.645 1.1 - 1.9 0.1 9
Size Increment ISO 3650/1 ISO 3650/0 1 - 9 1 9
mm mm Price SEK Price SEK 10 - 30 10 3
50 – 1
648.00
624.00
0.5 – 624.00 732.00 M47: 1 20,544.00 1.005 – 1
1 – 528.00 504.00 906.649 0 22,500.00 1.01 - 1.09 0.01 9
1.0005 – 624.00 332.40 906.648 1.1 - 1.9 0.1 9
1.001 - 1.009 0.001 426.00 332.40 1 - 24 1 24
1.01 - 1.49 0.01 315.60 366.00 25 - 100 25 4
1.5 - 1.9 0.1 315.60 588.00
2.0 - 5.5 0.5 342.00 708.00
6.0 - 9.5 0.5 516.00 720.00 M87: 1.001 - 1.009 0.001 9
10.0 - 20.0 0.5 636.00 864.00 906.652
20.5 - 25.0 0.5 672.00 912.00 906.651 1 41,400.00 1.01 - 1.49 0.01 49
30 – 768.00 924.00 0 42,000.00
40 – 852.00 1,032.00 0.5 - 9.5 0.5 19
50 – 924.00 1,140.00
60 – 972.00 1,176.00 10 - 100 10 10
70 – 1,068.00 1,236.00
75 – 1,104.00 1,380.00 M103: 1 41,640.00 1.005 – 1
80 – 1,140.00 1,416.00 906.655 0 50,520.00 1.01 - 1.49 0.01 49
90 – 1,248.00 906.654 0.5 - 24.5 0.5 49
100 – 1,332.00 25 - 100 25 4

M112: 1.0005 – 1
906.658
906.657 1 42,480.00 1.001 - 1.009 0.001 9 C11.304.Promet.20240517
0 53,880.00
1.01 - 1.49 0.01 49

0.5 - 24.5 0.5 49

25 - 100 25 4
