GAUGE BLOCKS www.promet.se

Select long gauge blocks from 125 mm

High quality long steel gauge blocks. These steel gauge blocks are available in the accuracy classes
0, 1 and 2 of ISO 3650. All gauge blocks have two coupling holes on both ends so that they can be
coupled by means of a toggle clamp.

 Hardness: approx. 800 HV.  Delivery on request with a DAkkS certificate,
 Expansion coefficient: α = 11.5 · 10‑6 K‑1. UKAS acknowledged.
 Cross-section: 35 x 9 mm.
 ISO 3650.  Gauge blocks of 1000 - 1500 mm incl. a
 Delivery in a luxurious wooden case with a DAkkS certificate, UKAS acknowledged
available on request.
traceable manufacturer measuring report.

831.937

Size/mm Item No. Price SEK Item No. Price SEK Item No. Price SEK

125 ISO 3650/2: 3,552.00 ISO 3650/1: 4,488.00 ISO 3650/0: 5,112.00
150 831.019 3,792.00 831.008 4,788.00 831.000 5,460.00
175 831.020 4,524.00 831.009 5,568.00 831.001 6,468.00
200 831.021 4,848.00 831.010 5,772.00 831.002 6,900.00
250 831.022 5,448.00 831.011 6,792.00 831.003 7,548.00
300 831.023 6,060.00 831.012 7,272.00 831.936 8,580.00
400 831.024 7,140.00 831.013 8,976.00 831.937 10,248.00
500 831.025 7,812.00 831.981 10,332.00 831.946 12,324.00
600 831.026 12,012.00 831.738 13,884.00 831.004 16,596.00
700 831.027 14,220.00 831.014 16,752.00 831.947 20,004.00
800 831.028 18,000.00 831.015 21,408.00 831.005 26,520.00
900 831.029 22,188.00 831.016 27,360.00 831.948 34,560.00
1000 831.030 27,840.00 831.017 33,720.00 831.006 44,040.00
831.031 831.018 831.007

Gauge block set consisting of 125, 150, 175, 200, 250, 300, 400 and 500 mm:

831.088 31,560.00 831.087 40,920.00 831.086 48,480.00

Gauge block set consisting of 600, 700, 800, 900 and 1000 mm:

831.091 76,560.00 831.090 93,000.00 831.089 117,600.00

Toggle clamp for long series gauge blocks

Toggle clamp for the coupling of gauge blocks over 100 mm which have coupling holes on
both ends. Very quick assembly by means of spring clamping device (with locking screw).

Item No. Description Price SEK C11.315.Promet.20240517

619.031 Toggle clamp for long 1,860.00
series gauge blocks

© 2024, Schut Geometrische Meettechniek bv 248 Promet Precision 2023/2024-D
