GAUGE BLOCKS www.promet.se

Select steel gauge blocks

High quality steel gauge blocks, can be very well wringed to make a combination size. The steel
gauge blocks are available in all accuracy classes of ISO 3650 (2, 1, 0, K). Only the most commonly
used sizes can be found in this catalog. Special sizes and sets are available on request, as well as
special sets for calibration of micrometers and calipers.

 Hardness: approx. 800 HV.  Delivery with a traceable manufacturer
 Expansion coefficient: α = 11.5 · 10‑6 K‑1. measuring report.
 Cross-section: 0.5 - 10 mm: 30 x 9 mm,
 Delivery on request with a DAkkS certificate,
> 10 mm: 35 x 9 mm. UKAS acknowledged.
 ISO 3650.
 Sets delivered in luxurious wooden case.
 Plastic cases for separate gauge blocks are

optionally available. For these cases see
plastic cases for gauge blocks elsewhere in
the catalog.

Steel gauge blocks in sets

Item Class Price Size Increment Pie-
No. SEK mm mm ces

M32: 1 12,876.00 1.005 – 1
831.915 0 15,060.00 1.01 - 1.09 0.01 9
831.914 1.1 - 1.9 0.1 9
1 - 9 1 9
10 - 30 10 3
50 – 1

M47: 1 20,940.00 1.005 – 1
831.911 0 24,120.00 1.00 - 1.09 0.01 10
831.910 1.1 - 1.9 0.1 9
2 - 25 1 24
50 - 100 25 3

M87: 0.5 – 1
831.909
831.908 1 29,880.00 1.001 - 1.009 0.001 9
0 35,400.00
Steel gauge blocks, per piece 1.00 - 1.50 0.01 51

Size Increment ISO 3650/1 ISO 3650/0 2.0 - 10.0 0.5 17
mm mm Price SEK Price SEK
20 - 100 10 9
744.00
0.5 – 624.00 624.00 M103: 1 34,920.00 0.5 – 1
1 – 576.00 744.00 831.907 0 41,640.00 1.005 – 1
1.0005 – 624.00 624.00 831.906 1.00 - 1.50 0.01 51
1.001 - 1.009 0.001 576.00 576.00 2.0 - 25.0 0.5 47
1.01 - 1.5 0.01 528.00 576.00 50 - 100 25 3
1.6 - 1.9 0.1 528.00 624.00
2.0 - 5.5 0.5 576.00 624.00
6.0 - 10.0 0.5 576.00 672.00 M112: 0.5 – 1
10.5 - 15.0 0.5 600.00 672.00 831.905
15.5 - 20.0 0.5 600.00 672.00 831.904 1 37,560.00 1.0005 – 1
20.5 - 25.0 0.5 600.00 744.00 0 44,520.00
30 – 624.00 744.00 1.001 - 1.009 0.001 9
40 – 624.00 744.00
50 – 624.00 744.00 1.00 - 1.50 0.01 51
60 – 624.00 744.00
70 – 624.00 780.00 2.0 - 25.0 0.5 47
75 – 672.00 912.00
80 – 696.00 912.00 50 - 100 25 3
90 – 696.00 1,020.00
100 – 780.00 M122: 0.5 – 1
831.903
831.902 1 41,760.00 1.0005 – 1
0 50,640.00
1.001 - 1.009 0.001 9

1.00 - 1.50 0.01 51

1.6 - 1.9 0.1 4

2.0 - 25.0 0.5 47 C11.210.Promet.20240517

30 - 70 10 5

75 – 1

80 - 100 10 3
