www.promet.se STRAIGHT EDGES
Bridge-type straight edges Item No. l x w Weight Flatness Price
mm kg µm SEK
Made of special close-grained cast iron.
Tension free. DIN 876/1:
Flatness according DIN 876: 403.658 500 x 40 6 15 2,544.00
403.659 750 x 45 9 18 2,820.00
class 1: hand scraped, 403.680 1000 x 50 17 20 5,088.00
class 0: fine scraped. 403.690 1 1500 x 60 45 25 10,848.00
403.692 1 2000 x 70 65 30 16,512.00
Triangular straight edges 403.698 1 3000 x 90 210 40 31,920.00
DIN 876/0:
On two sides scraped, triangular straight edge 403.657 500 x 40 6 6 3,060.00
with screwed-in handles. The edge between the 403.660 750 x 45 9 7 3,312.00
scraped sides (45° or 60°) has been accurately 403.679 1000 x 50 17 8 6,252.00
processed. The third side has been ground, and 403.691 1 1500 x 60 45 10 13,860.00
recessed for weight reduction at the larger types 403.696 1 2000 x 70 65 12 20,544.00
(from 500 mm). 403.697 1 3000 x 90 210 16 36,600.00
Tension free. 1 Delivery ex Groningen, Netherlands.
Flatness of both scraped sides according
Item No. l x w/mm Weight/kg Price SEK
DIN 876:
class 1: hand scraped, Triangular straight edge 45°, DIN 876/1:
class 0: fine scraped. 403.525 250 x 50 2 1,896.00
403.550 500 x 75 7 4,092.00
403.575 750 x 90 15 6,444.00
403.600 1 1000 x 120 27 9,672.00
Triangular straight edge 45°, DIN 876/0:
403.524 250 x 50 2 2,556.00
403.549 500 x 75 7 5,100.00
403.574 750 x 90 15 7,680.00
403.599 1 1000 x 120 27 11,604.00
Triangular straight edge 60°, DIN 876/1:
403.425 250 x 45 3 2,052.00
403.450 500 x 60 6 3,864.00
403.475 750 x 90 16 6,144.00
403.500 1 1000 x 100 28 9,084.00
Triangular straight edge 60°, DIN 876/0:
403.424 250 x 45 3 2,520.00
403.449 500 x 60 6 4,872.00
403.474 750 x 80 16 7,404.00
403.499 1 1000 x 100 28 11,292.00 C09.207.Promet.20240517
1 Delivery ex Groningen, Netherlands.
