Page 218 - Schut Catalog
P. 218
PROTRACTORS www.promet.se
Universal digital bevel protractor
This stainless steel, digital bevel protractor is available with blades from 150 to 1000 mm. The
blades and all the measuring faces are hardened.
Measuring range: ± 360°. On/off switch.
Resolution: 1', or decimal 0.01°. Reset/preset/hold functions.
Accuracy: ± 2'. Control with 5 keys for several functions.
Repeatability: 1'. Fine adjustment.
Indication switchable from degrees and Delivery in a wooden case without blade.
Power supply: 1 battery type CR2032.
minutes to decimal degrees.
+ and - direction reversible.
Per 90° adjustable.
Data output, Mitutoyo Digimatic compatible.
Single blades
Item No. Description Price SEK Item No. Blade length/mm Price SEK
82.80
855.820 Bevel protractor 14,028.00 909.380 150 110.40
909.381 200 140.40
Options: 909.382 300 217.20 C08.203.Promet.20240517
495.157 Spare battery type CR2032 6.00 909.383 500
905.409 Data cable 2 m 516.00 855.827 1000 4,836.00
© 2024, Schut Geometrische Meettechniek bv 218 Promet Precision 2023/2024-D
