P. 217
www.promet.se PROTRACTORS
Universal digital bevel protractors
Digital bevel protractors made of stainless steel, with blades of 150, 200 or 300 mm. The blades
and all the measuring faces are hardened.
Measuring range (switchable): 1x 360°, Automatic switch-off after 10 minutes of idle
2x 180°, time with storage of the displayed measuring
4x 90°. value.
Resolution: 1', or decimal 0.01°. Proximity data output.
Accuracy: ± 2'. Reset/preset/hold functions.
Clamping spring system for blade. Fine adjustment.
Indication switchable from degrees and Power supply: 1 battery type CR2032.
minutes to decimal degrees.
856.688
Complete bevel protractors Single blades
Item No. Blade length/mm Price SEK Item No. Blade length/mm Price SEK
540.00
856.688 150 12,216.00 856.685 150 672.00
856.689 200 12,348.00 856.693 200 720.00
856.690 300 12,468.00 856.687 300
Options:
495.157 Spare battery type CR2032 6.00
856.694 Prism base 888.00
856.695 Ledge 684.00 C08.202.Promet.20240517
840.666 Proximity USB cable (2 m)3,000.00
856.694 856.695
© 2024, Schut Geometrische Meettechniek bv 217 Promet Precision 2023/2024-D
