Steel parallel blocks

Parallels to position and layout workpieces in e.g. clamping jaws for drilling, grinding, milling and
measuring. The workpieces and assemblies can easily be set up to the desired working height.

 Parallelism of the two measuring faces:  Ground in matched pairs.
± 0.005 mm.  Produced of a high-grade steel alloy.
 Delivery in a wooden case with a declaration
 Size deviation (height): ± 0.01 mm.
 Hardness: 55 HRC. of conformity.

Item No. Length Price Width Height
mm SEK mm mm

Set of 12 pairs: 1,020.00 10
909.800 100 1,188.00 14 - 16 - 18 - 20 - 22 - 24 -
909.804 125 1,404.00 26 - 28 - 30 - 32 - 35 - 40
906.995 150 10
14 - 16 - 18 - 20 - 22 - 24 -
906.996 Set of 14 pairs: 1,104.00 8 26 - 28 - 30 - 32 - 35 - 40 -
909.802 100 1,404.00 10 45 - 50
909.805 125 1,584.00 12
906.996 150 14 11 - 16 - 21 - 26 - 31 - 36
13 - 18 - 23 - 28 - 33 - 38
(Only available in sets.) Set of 24 pairs: 2,628.00 15 - 20 - 25 - 30 - 35 - 40
909.803 100 2,892.00 17 - 22 - 27 - 32 - 37 - 42
909.806 125 3,468.00
906.997 150

Adjustable parallel set

Set of 6 adjustable parallels. The parallels consist of 2 precisely ground tapered parts dovetailed
together to ensure easy setting. These allow you to quickly clamp a workpiece in the correct position
on a workbench, set a measuring instrument or check the internal dimensions of two parallel surfaces.

Parallel Measuring Measuring face
A range/mm length/mm
B
C 9.5 - 12.7 45 Item No. Size/mm Price SEK C09.311.Promet.20240517
D 12.7 - 17.5 54 910.400 9.5 - 57.1 mm 708.00
E 17.5 - 23.8 69
F 23.8 - 33.3 90
33.3 - 44.5 107
44.5 - 57.1 117
