www.promet.se DIAL INDICATOR STANDS

Bases for dial indicator stands

A solid base is essential for accurate measurements. The dial indicator arms can be mounted on a
strong magnetic or vacuum base.

908.971

908.969

908.976

908.967

908.968

402.196

908.965

908.977

Item No. Description Dimensions Magnetic force */N Thread Price SEK
l x w x h/mm 800 (S) M8 x 1.25 223.20
1000 (S) M8 x 1.25 315.60
908.971 V‑groove 60 x 50 x 55 1500 (S) M8 x 1.25 948.00
908.970 V‑groove 74 x 50 x 55 400 (S) M5 x 0.8 246.00
908.969 flat base 118 x 50 x 52 170 (S) M5 x 0.8 271.20
908.967 V‑groove 36 x 30 x 35 400 (P) M8 x 1.25 434.40
908.976 flat base 30 x 30 x 30 300 (P) M8 x 1.25 237.60
908.968 flexform 75 x 46 x 55 M8 x 1.25 378.00
908.965 cylinder d1 M8 x 1.25
908.977 vacuum base ø 40 x 30 2,076.00
402.196 granite base ø 90 x 25 d2
150 x 100 x 40

* S = switchable magnet; P = permanent magnetic force.

Fixing clamps for dial indicator stands

Item No. Fixing clamp ø/mm Price SEK
d1 d2

907.443 10 8 / 4 108.00 C06.305.Promet.20240517
907.442 10 8 / 6 108.00
906.398 12 8 / 6 104.40
907.440 12 10 108.00
907.444 14 8 / 6 156.00
906.399 20 12 318.00
907.441 20 14 362.40
