PROBES www.promet.se

Digital absolute measuring probes

The measuring probe, which replaces the conventional analog probe more and more. These probes,
that combine the advantages of the analog and not absolute digital models, are a solution to measuring
systems which have to process the measuring data in a PC.

Configuration: Technical data:
 Probe (clamping shaft 8h6) fixed via a cable  A maximum of 240 measurements per second.
 Repeatability: < 0.15 µm.
(2 m) to the electronics module.  Accuracy:
 T‑CON connector.
 Cable (standard up to 5 m). DP‑2S, DP‑2P: ± 1 + 0.05 %K,
 Supply module (necessary with RS232C DP‑5S, DP‑5P: ± 1 + 0.05 %K,
DP‑10S, DP‑10P: ± 1 + 0.06 %K,
module, and with more than five probes on a in which K is the displacement (in mm).
board or module).  Protection: IP65.
 RS232C/USB module or digital absolute  Measuring force S-types: 0.7 N,
measuring probe board (supports up to 100 P-types (at 0.4 bar pressure): 0.8 N.
probes).  Also available on request as low measuring
force Feather Touch models.

9p cable
male-female

RS232C/USB M F MF M 30.0 Type DP-S
(interface) and ø3.5 1.0
supply module ø3.0 8.0 ø8h6
ø3.5 4.5 F1 Fully Extended
9p cable 2.0 F2 Fully Retracted
male-female C
Type DP-P
Terminator 2.0
(male) C ø8h6
F1 Fully Extended
F F2 Fully Retracted

Item No. Type Measuring Max. Probe movement Dimensions/mm Price
range/mm travel/mm C F1 F2 SEK

360.880 DP‑2S ± 1 3 spring push 46 13.9 10.9 8,340.00
360.881 DP‑5S ± 2.5 6 spring push 65 17.4 11.4 9,312.00
360.882 DP‑10S ± 5 11 spring push 89 25.4 14.4 9,996.00
360.883 DP‑2P ± 1 3 pneumatic push 52 13.9 10.9 8,976.00
360.884 DP‑5P ± 2.5 6 pneumatic push 71 17.4 11.4 9,660.00
360.885 DP‑10P ± 5 11 pneumatic push 96 25.4 14.4 10,332.00

360.852 T‑CON connector (has to be ordered separately per probe) 600.00

360.835 Supply module (required when using a RS232C module and when connecting 6,828.00 C05.203.Promet.20240517
more than five probes to a board or module, excl. power cable) 62.40

420.300 Power cable 10,764.00
360.890 Digiprobe PCI board Orbit 3 8,736.00
360.888 Digiprobe USB module Orbit 3
348.287 Cable 3 m between electronic module and board/module 208.80
348.288 Cable 5 m between electronic module and board/module 237.60
