DIAL INDICATOR STANDS www.promet.se

Dial indicator stands 908.953/959 908.960

 Clamping shaft ø 8 mm for dial indicators
and probes (except 910.341: ø 6 mm), and
dovetail joint for lever-type dial test indicators
(908.957 without dovetail joint).

 With fine adjustment (except 908.962/964/957).
 Arm with mechanical central clamping device

(908.954/955: hydraulic).
 On/off switchable magnetic base with V‑groove,

except 908.964 and 910.341 (permanent
magnetic force), 908.961 (vacuum base)
and 908.975 (flexform base with locking
mechanism and permanent magnetic force).
 Various bases available.

908.962

910.341

908.954/955 908.964
908.956/957

908.975 908.961

Item No. Clamping Arm Description Dimensions Magnetic Thread Price
length 1/mm of base l x w x h/mm force 2/N of base SEK
426.00
908.953 mechanical 320 V‑groove 58 x 50 x 55 600 (S) M8 x 1.25 456.00 C06.304.Promet.20240517
908.959 mechanical 340 V‑groove 60 x 50 x 55 800 (S) M8 x 1.25 516.00
908.960 mechanical 285 V‑groove 60 x 50 x 55 800 (S) M8 x 1.25 816.00
908.954 hydraulic 380 V‑groove 58 x 50 x 55 600 (S) M8 x 1.25 864.00
908.955 hydraulic 380 V‑groove 60 x 50 x 55 800 (S) M8 x 1.25 478.80
908.962 mechanical 150 V‑groove 36 x 30 x 35 400 (S) M5 x 0.8 322.80
908.964 mechanical cylinder ø 30 x 25 170 (P) M8 x 1.25 274.80
910.341 mechanical 65 cylinder ø 25 x 25 100 (P) M5 x 0.8 612.00
908.975 mechanical 60 flexform 75 x 46 x 55 400 (P) M8 x 1.25 576.00
908.961 mechanical 280 vacuum base ø 90 x 25 800 (S) M8 x 1.25 465.60
908.956 mechanical 280 V‑groove 60 x 50 x 55 800 (S) M8 x 1.25 477.60
908.957 mechanical 360 V‑groove 60 x 50 x 55 M8 x 1.25
320

1 The outstretched length between base and clamping shaft.
2 S = switchable magnet; P = permanent magnetic force.
