www.promet.se PROBE ACCESSORIES

Clamping bush 6 0.7 Inserts

12 Many inserts with thread
M2.5 are available. See the dial
ø10h8 indicator accessories section for
ø8H7 more information.
ø1.5
M4 Retraction levers
VKE VKD
Universal retraction levers, bottom or top
780.398 Price SEK mounted, compatible with a wide range of
115.20 probes and dial indicators. You can find various
Item No. Description 43.20 models in the dial indicator accessories section.

780.398 Clamping bush VKE
780.397 Clamping screw VKD

Clamping bush

7 11 17.5
25.3

Item No. Description ø8H7 Retraction device DZ801
906.497 Clamping bush ø10h7
Pneumatic
Price SEK retraction device
313.20 for Magnescale and
TESA gauges, with
Probe holder 1 meter hose and air
tube connector.
Probe holder for for surfacemounting.
 Clamping shaft: ø 8 mm. Item No. Description Price SEK
 For attaching with M4 bolts. 344.465 Retraction device 1,944.00
 Material: anodized aluminum.

=30=

ø8 H7 ø4.5 THRU (2x) Clamp collar with dovetail

12 8=20= ø4.5 THRU For clamping TESA GT31 probes and e.g.
6=10= lever type dial indicators.
40  Fastening points:

ø 5.6 mm, ø 9.5 mm
and with dovetail.

Item No. Description M4x0.7 - 8 DEEP (2x) Item No. Description Price SEK C05.316.Promet.20240517
993.054 Probe holder 780.208 Clamp collar 348.00
Price SEK
600.00
