www.prenar.ee GAUGE BLOCKS
Select tungsten carbide gauge blocks
High quality tungsten carbide gauge blocks, can be very well wringed to make a combination size.
The tungsten carbide gauge blocks are available in all accuracy classes of ISO 3650 (2, 1, 0, K). Only the
most commonly used sizes can be found in this catalog. Special sizes and sets are available on request.
Hardness: approx. 1500 HV. Sets delivered in luxurious wooden case.
Expansion coefficient: α = 4.5 · 10‑6 K‑1. Plastic cases for separate gauge blocks are
Cross-section: 0.5 - 10 mm: 30 x 9 mm,
optionally available. For these cases see
> 10 mm: 35 x 9 mm. plastic cases for gauge blocks elsewhere in
ISO 3650. the catalog.
Delivery with a traceable manufacturer
Tungsten carbide gauge blocks in sets
measuring report.
Delivery on request with a DAkkS certificate, Item Class Price Size Increment Pie-
No. EUR mm mm ces
UKAS acknowledged.
M32: 1 1.005 – 1
828.592 0 1.01 - 1.09 0.01 9
828.606 1.1 - 1.9 0.1 9
1 - 9 1 9
10 - 30 10 3
50 – 1
M46: 1.001 - 1.009 0.001 9
828.590
828.604 1 1.00 - 1.09 0.01 10
0
1.1 - 1.9 0.1 9
2 - 10 1 9
20 - 100 10 9
M47: 1 1.005 – 1
828.589 0 1.00 - 1.09 0.01 10
828.603 1.1 - 1.9 0.1 9
2 - 25 1 24
50 - 100 25 3
M87: 0.5 – 1
828.587
828.601 1 1.001 - 1.009 0.001 9
0
Tungsten carbide gauge blocks, per piece 1.00 - 1.50 0.01 51
Size Increment ISO 3650/1 ISO 3650/0 2.0 - 10.0 0.5 17
mm mm Price EUR Price EUR
20 - 100 10 9
0.5 – M103: 1 0.5 – 1
1 – 828.585 0 1.005 – 1
1.0005 – 828.599 1.00 - 1.50 0.01 51
1.001 - 1.009 0.001 2.0 - 25.0 0.5 47
1.01 - 1.50 0.01 50 - 100 25 3
1.6 - 1.9 0.1
2.0 - 5.5 0.5
6.0 - 10.0 0.5 M112: 0.5 – 1
10.5 - 15.0 0.5 828.584
15.5 - 20.0 0.5 828.598 1 1.0005 – 1
20.5 - 25.0 0.5 0
30 – 1.001 - 1.009 0.001 9
40 –
50 – 1.00 - 1.50 0.01 51
60 –
70 – 2.0 - 25.0 0.5 47
75 –
80 – 50 - 100 25 3
90 –
100 – M122: 0.5 – 1
828.583
828.597 1 1.0005 – 1
0
1.001 - 1.009 0.001 9
1.00 - 1.50 0.01 51
1.6 - 1.9 0.1 4
2.0 - 25.0 0.5 47 C11.204.Prenar.20240422
30 - 70 10 5
75 – 1
80 - 100 10 3
