www.prenar.ee GAUGE BLOCKS
Tungsten carbide gauge blocks
Tungsten carbide gauge blocks with an excellent price-performance ratio and a low expansion
coefficient. High resistance against corrosion.
Hardness: 70 - 72 HRC.
Expansion coefficient: (8.5 ± 1)·10‑6/°C.
Cross-section: 0.5 - 10 mm: 30 x 9 mm,
> 10 mm: 35 x 9 mm.
ISO 3650.
Sets delivered with a manufacturer measuring
report.
Delivery in plastic case and sets in wooden
case.
Empty wooden cases with cutouts and size
indications for gauge block sets are optionally
available. For these cases see wooden cases
for gauge block sets elsewhere in the catalog.
Tungsten carbide gauge blocks, per piece Tungsten carbide gauge blocks in sets
Size Increment ISO 3650/1 ISO 3650/0 Item Class Price Size Increment Pie-
mm mm Price EUR Price EUR No. EUR mm mm ces
0.5 – M32: 2 1.005 – 1
1 – 906.634 1 1.01 - 1.09 0.01 9
1.0005 – 906.633 0 1.1 - 1.9 0.1 9
1.001 - 1.009 0.001 906.632 1 - 9 1 9
1.01 - 1.50 0.01 10 - 30 10 3
1.6 - 1.9 0.1 50 – 1
2.0 - 10.0 0.5
10.5 - 15.0 0.5
15.5 - 25.0 0.5 M47: 2 1.005 – 1
30 – 906.637 1 1.01 - 1.09 0.01 9
40 – 906.636 0 1.1 - 1.9 0.1 9
50 – 906.635 1 - 24 1 24
60 – 25 - 100 25 4
70 –
75 –
80 – M87: 1.001 - 1.009 0.001 9
90 – 906.662
100 – 906.661 2 1.01 - 1.49 0.01 49
906.660 1
0 0.5 - 9.5 0.5 19
10 - 100 10 10
M112: 1.0005 – 1
906.643
906.642 2 1.001 - 1.009 0.001 9 C11.303.Prenar.20240422
906.641 1
0 1.01 - 1.49 0.01 49
0.5 - 24.5 0.5 49
25 - 100 25 4
