www.prenar.ee MEASURING STANDS

Measuring stands

Measuring stands with a granite base
in two models with a competitive price-
performance ratio.
 Clamping shaft: ø 8 mm.
 Max. measuring height: 250 mm.
 Anti drop facility.
 Granite table.
 DIN 876/0.
 Own product.

402.165

Item No. Measuring Flatness Dimensions Column Effective arm Price
height/mm table/µm table l x w x h/mm ø/mm length/mm EUR
150 x 100 x 40
402.165 150 10 250 x 200 x 55 25 62
402.168 250 10 35 100

Measuring stand Measuring table

Heavy-duty precision stand with alumina Grooved measuring table made of alumina
ceramic grooved table and plain column. ceramics as applied to measuring stand 334.690,
 Clamping shaft: ø 8 mm. with the typical advantages of ceramics: high
 Max. measuring height: 135 mm. degree of hardness and wear resistance.
 Effective arm length: 62 mm.  Flatness: ± 2 µm.
 Measuring table: 80 x 80 x 22 mm.  Dimensions: 80 x 80 x 22 mm.
 Flatness table: ± 2 µm.  Bottom-side: 3 tapped holes M6.
 Column: ø 25 mm.
 Base: 150 x 89 x 37 mm.
 Anti drop facility.
 Own product.

Item No. Description Price EUR Item No. Description Price EUR C06.272.Prenar.20240422
334.690 Precision stand 841.078 Measuring table

169
