www.prenar.ee DIAL INDICATOR STANDS
Bases for dial indicator stands
A solid base is essential for accurate measurements. The dial indicator arms can be mounted on a
strong magnetic or vacuum base.
908.971
908.969
908.976
908.967
908.968
402.196
908.965
908.977
Item No. Description Dimensions Magnetic force */N Thread Price EUR
l x w x h/mm 800 (S) M8 x 1.25
1000 (S) M8 x 1.25
908.971 V‑groove 60 x 50 x 55 1500 (S) M8 x 1.25
908.970 V‑groove 74 x 50 x 55 400 (S) M5 x 0.8
908.969 flat base 118 x 50 x 52 170 (S) M5 x 0.8
908.967 V‑groove 36 x 30 x 35 400 (P) M8 x 1.25
908.976 flat base 30 x 30 x 30 300 (P) M8 x 1.25
908.968 flexform 75 x 46 x 55 M8 x 1.25
908.965 cylinder d1 M8 x 1.25
908.977 vacuum base ø 40 x 30
402.196 granite base ø 90 x 25 d2
150 x 100 x 40
* S = switchable magnet; P = permanent magnetic force.
Fixing clamps for dial indicator stands
Item No. Fixing clamp ø/mm Price EUR
d1 d2
907.443 10 8 / 4 C06.305.Prenar.20240422
907.442 10 8 / 6
906.398 12 8 / 6
907.440 12 10
907.444 14 8 / 6
906.399 20 12
907.441 20 14
